TH Type Bucket Elevator

TH Type Bucket Elevator is a kind of continuousvertical lifting equipment with chain type bucket to process bulk material. Itis mainly used for lifting bulk material and crushed material with the propertyof low hardness. It is widely used in power, chemistry, metallurgy, buildingmaterial, light industry, grain, mining and etc. The lifted material with thetemperature under 250℃. It has the features of high capacity, reliable working, small areaneeded, high lifting height and easy maintenance. In the driving system, it hasthe high reliable non-return structure to prevent temporary power off or otherfault causing shut off under the loading condition to make drive and liftinghopper return moving to cause fault.

Our advantages of TH Type Bucket Elevator:

1. Compact Machine Structure, small overalldimension, small space needed.

2. Adopt the taking out type material loadingand mixing type material discharging. The hopper volume is big with highdensity layout. It has the feature of big lifting scope, high lifting heightand high transportation capacity.

3. Each section and maintenance door have thesealing device to make sure no dust outlet to realize clean and friendlyenvironment production.

4. Drive sprocket wheel is a overallstructure, the surface has been specially strengthen processed. It has thefeatures of easy operation, high strength and wearing resistance.

5.Adopt low alloy high strength round ringchain as driving part. Under the special technology process, it has thefeatures of anti-pulling strength, good wearing resistance, long time using,good hopper connection, and easy to be maintenance.

TH Bucket Elevator is mainly consist of drive device,shell, ring chain, hopper and maintenance platform. Its main structure featureas below:

1.Bucket elevator ring chain is made of low alloysteel with forging process. The surface has been special strengthen processed.It has high tension resistance and wearing resistance.

2.Elevator middle shell is made of bend plate withwelding assembly. It has the features of light weight, good rigidity, smallwelding transformation. It improve the equipment overall performance largely.

3.There are a lot of maintenance doors in the shell.It is convenient to observe the chain and hopper running condition. It is alsoconvenient to change hoppers and chains.

4.There is tension device at the bottom to make surethat there will be enough pretension force of the ring chain during theworking. At the same time, there is a automatic self aligning device at thebottom of the chain wheel device in order to prevent the chain wheel haveuneven tension to cause inclined phenomenon to cause equipment fault.

5.There is sealing device between shells and betweenmaintenance door and shell. It is clean and friendly environment.

6.There is a high reliable non-return device . Notonly to prevent the driver part and hopper return move, but also to make thedrive device structure compact and small area needed.
