high quality Automatic Loading and Unloading System with woodworking cnc router

Type:A1-48ABP Machining Centre with Automatic Loading and Unloading System

Working area:1300*2500*200(mm)

Traveling speed:40 m/min(MAX)

Cutting speed10~16 m/min(MAX)

Spindle parametersHSD air cooling,9.5KW 24000rpm,Automatic tool change

Controller OSCustom SYNTEC system with PC

Drill UnitsItaly FAM 5V+4H

Driving systemXY:750W DELTA servo  Z:750W DELTA brake servo

Working VoltageAC380V/3PH/50HZ

Electrical accessoriesTaiwan Delta VFD/ Schneider Low voltage electrical components/high quality cable

Driving SystemGerman HERION pinion/Taiwan PMI rail/Taiwan PMI ball screw

Table StructureDouble layers of multi-point high efficient vacuum absorbable countertop

Safety systemOverrun protection/Emergency stop protection/Limiting position / Air pressure alarm / Safety shield / interruption of power supply when the door is open/Electrical emergency etc

CompositionAutomatic loading lift, Material feeding system, Dust absorption structure,7.5kw, Accurate positioning structure, Smart cutting machining centre, Unloading belt machine, High efficiency vacuum pump, PC version control cabinet

Size9000*2000*2200(mm)

Weight2.9T

Vacuum system7.5KW Vacuum pump

Accessories1Tool box（including tools）1 set

2ER32 spring collet 1/28 pcs

3Cutting tool8 pcs

4Table vacuum plug120 pcs

5High quality φ10 sponge rubber seal10m

6Documents1 copy
