Blue SMD LED Flexible Strip

Brand Name	OPLED		Place of Origin	China
Model Number	OP-SFL3528-1260

Delivery Time:5-7days
Certification:CE,ROHS

Green / Blue SMD LED Flexible Strip 24V , IP68 24W 5m smd3528

60leds/m smd3528 led strip lamps Model: led strip lamps OP-SFL3528-1260 Size: led strip lamps 5000*8mm (every 3 leds can be cut) Material: led strip lamps Copper PCB, epoxy resin, PC Tubes Protection rate: led strip lamps IP68, epoxy resin cover, PC Tubes Application: led strip lamps - lighting, decoration

Quick Detail:

LED rope light, LED tape, LED ribbon, LED kit Voltage:DC12V,DC24V are optional Model: OP-SFL3528-1260 Power:4.8W/m,24W/roll LED No.: 60LEDs/m,300LEDs/roll Size: 5000*8mm (every 3 led can be cut) Length: 5m one roll Color Available: red/yellow,blue,green,white,warm white Material: Copper PCB, epoxy resin ,silicone tube Protection rate: IP67 Viewing angle:120° Lumen: 5-6lm/ LED Certificate:CE/ROHS Warranty:2years Application: Edge lighting for signage,light box,etc.

Description:

Make use of? 3528 SMD LED which the size is?3.5mm×2.8mm×1.85mm The height is?4 mm; can be used in small areas 60 SMD LEDs/m,?5m/roll,?8mm/10mm?width PCB?,brown or white PCB is available. Good heat diffusion, the life of chip can be better guaranteed 3M?self-adhesive tape in the back, easy installation Working voltage: 12V DC Excellent flexibility LED quantity & strip length can be customized Life?spain:80,000hrs Working temperature:-20℃?to +60℃ Store temperature:-30℃?to +80℃

Applications:

Cove lighting Architectural lights for canopy, corridor, window, archway Backlight or edge lighting for signage DIY lights for home use Path and contour marking Decorative lights for holiday, event, show, exhibition

Specifications:

Product	60leds/m smd3528 led strip lamps
Model	OP-SFL3528-1260
Lumen	6-8lm/led
Light Source	3528SMD (300LEDs/roll)
LED No./Meter:	60LEDs/Meter
Power(W/m):	≤4.8W/m
Current(mA/m):	≤400mA/m
Protection Rate	IP68 (outdoor), epoxy resin cover, PC Tubes
Light color	Red, Yellow, Green, Blue, White
Strip Size/roll	5000*8mm (every 3 led can be cut)
Viewing Angle	120°
Material	Copper PCB (White/Brown/Black available) epoxy resin, PC Tubes
Input Voltage	DC12V/24V
Warranty	2 years
Life	80,000hrs
Working temperature	-20°C to +60°C
Storage temperature	-35°C to +80°C
Certificate	CE, ROHS

Packing Picture:

Related products:

Production View:

Customer Feedback:

Team View:

OEM Sevices Tips:

FAQ:

Q1: Can I have samples to test?

A: Yes,we are pleased to supply samples to test and check quality,mixed sample order is available. Please note, free samples is not acceptable.

Q2: Do you have any MOQ limited?

A: Our MOQ EXW is 5pcs, Our MOQ FOB is 100pcs.

Q3: What’s the lead time?

A: Sample :1-5days.

?? Mass production: 7-10days.

Q4:How do you ship the goods and how long does it take?

A: We usually ship by DHL,UPS,FEDEX,TNT. It usually takes 3-5days to arrive.

By air,by sea are also acceptable.

Q5: Do you offer guarantee for your products?
