Shandong Sinomtp Construction Equipment Company Limited: Yan'an, Shaanxi, China; Main products: SINOTRUCK HOWO, dump truck, tractor, concrete mixer truck, concrete pump truck, cargo truck, water tank, SDLG, roller, loader,

Home > Products > QINGONG > QINGONG LT214 heavy duty vibratory rollers

QINGONG LT214 heavy duty vibratory rollers

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	QINGONG		Place of Origin	China
Model Number	LT214

Product Description

QINGONG LT214 heavy duty vibratory rollers

LT220B , LT218B , LT216B , LT214 , LT212 , LT210 heavy duty vibratory rollers effect powerful centrifugal force and great static linear load, They are suitable for non-cohesive materials, such as sandy soil, gravel, crushed stones, rock fillings and slightly cohesive soils, designed for large foundation constructions such as high-class highways, mines, dams, airports, harbors, railways and industrial areas etc.
Main Features
      Mechanical travel drive, double amplitude, hydraulic vibration and steering with optimal function/price ratio and reliable performance.
      Reliable D6114 or YC6108 diesel engine for convenient operation and maintenance.
      Two sets of brake devices, a hand brake and foot pedal brake, assures the machine's safety and dependability.
      Spacious and comfortable cab mounted on top quality rubber damping elements.
      World advanced technology is adopted for the hydraulic vibration technology, high in reliability, simple and convenient in maintenance, and low in cost.
      Equipped with padfoot or removal padfoot as option.

Main Technical Parameters
		LT212	LT214	LT216B	LT218B	LT220B
Operating mass	Kg	12000	14000	16000	18000	20000
Static linear load	N/cm	276	342	378	415	450
Vibration amplitude	Hz	30	30	30	30	30
Vibration frequency	mm	1.8	1.8/0.9	2.0/1.0	1.0	2.0
Centrifugal force	kN	270/140	200/150	320/180	340/200	360/220
Travel speed	Hz
1st gear		1.8	2.0	2.0	2.0	2.0
2nd gear		3.7	4.0	4.0	4.0	4.0
3rd gear		9.7	10.5	10.5	10.5	10.5
Grade ability	%	35	35	35	35	35
Turning angle		35	35	35	35	35
Ground clearance	mm	360	432	432	432	432
Electrical voltage	v	24	24	24	24	24
Turning radius	mm	7000	7000	7500	7500	7500
Vertical oscillate action		8	8	8	8	8
Type size		17.5-25	23.1-26	23.1-26	23.1-26	23.1-26
Overall length	mm	5640	5820	5820	5820	5820
Overall width	mm	2258	2278	2278	2280	2280
Overall height	mm	2970	3000	3000	3000	3000
Vibration round width	mm	2100	2100	2100	2100	2100
Drum diameter	mm	1400	1600	1600	1600	1600
Drum rim thickness	mm	24	24	32	40	46
Wheelbase	mm	3080	3160	3160	3160	3160
Diesel model		YC 6108G	YC 6108G	YC6108ZG	YC6108ZG	D6114ZG6B
Diesel power	kW	85	88	110	110	132
Diesel speed	r/min	2000	2000	2000	2000	2000
Fuel tank capacity	L	180	180	180	180	180
Hydraulic tank capacity	L	150	150	150	150	150
