Automatic Folder Gluer ZH-880Y

Main technical parameters:

Paper weight: 180-800m/² paperboard, E flute microwave corrugated board

Gluing mouth 6-30mm

Max speed: 200-300m/min  40000-50000pcs/hour

Type: Stand box, Double sides box

Dimension: 9000*1400*1400mm(L*W*H)

Weight: 2000kg

Required power: 5kw  380v

Optional functions : For CD, EMS courier boxes, for socks paper boxes, for documents files

Basic funtions:

1. 180°for the first creasing line, 135°for the third line more suitable for paper boxes which needs to be running on automatic packing flow line cigarette box, wine box, cosmetics box etc easier to open the molding per-pack boxes

2. Suitable for micro corrugated paper boxes for hardware(flute E/F/N)

3. The new modularization and humanized design, easy operation, have a variety of functions, can produce the most complex box-type, can production capable for most complicated boxes

4. Using the world brand Japanese Nitta plane belt

5. Man-machine interface, PLC operating system and remote control( optional)

6. Cold, hot glue spraying system(optional)

Other details:

Model: ZH-880Y

minimum order : 1set

Production Capacity: 15sets/month

Payment Terms: T/T

Place of Origin: China
