Wire Mesh Welding Machine

Brand Name	jiaoyang		Place of Origin	China
Model Number	GWC-1200A

The machine adopts electrical electronic synchronous control technique,both welding time and cent-control welding is composed of digital and integrated electric circuit.this operation is accurate,it has stable function,firm welded point andwithout welded traearn and operate.the machine is equipped with precise equipment for weft ctting and position so the length of wefts is identical and regular,it is unnecessary to slice the sh panel drawing system adopts elastic tension link and mesh opening positioning device.it is easy to regulate mesh hole and mesh opening size is rather accurate,welding aperture could adjust randomly within certain range.
wire diameter:1.4-2.5mm
welding aperture:50*50-200*200mm
width of mesh:1200/1600mm
number of electrodes:25
welding speed:60time/min
rated voltage:380v
rated electrical power:72kva
run area:12*3m
external power required min 50kva 150 or less 70-95mm square aluminum
number of operation:2
compression spring:28*11*138
motor:2.2kw
on contacts:16*100
pole pieces:35*35*18
transformer:56kva*2
