Spray bottle—washing machine
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Place of Origin | China |
Product Description
Establish working routine willfully, easy to use. Operating speed stability. Speed smoothing.
1.Technology specification
|
Model |
CX-18 |
CX-12 |
|
Production capacity |
3000-6000 b/h |
2000-4000 b/h |
|
Bottle neck |
Ф50-ф100mm |
Ф50-ф100mm |
|
Bottle height |
160-320mm |
160-320mm |
|
Mainframe power |
0.75kw |
0.75kw |
|
Outer size |
1600×1500×1700(mm) |
1200×1100×1700(mm) |
|
Machine weight |
1200kg |
800kg |
2.Technology parameter
|
Washing medium |
Sterile water |
|
Washing time |
3s |
|
Drying time |
2s |
|
Water pressure |
0.2Mpa-0.4Mpa |
3.Operation principle
Conveyor belt will put needed cleaning bottles into the bottle screw , due to the bottle inputting screw and star wheel catch plate are continuously operating in-phase which will synchronously convey the needed cleaning bottles to the center transferring manipulator , and the manipulator along with the rotary table are spraying and washing the needed cleaning bottles , it will revert into the start-off state after completed , then the bottle outputting star wheel catch plate makes the cleaned bottle out , so the whole process is completed .
