finger-touch whiteboard--NHBoardTGN70

1.Technology:Resistance of Memebrane Techonology,through detecting the resistance to achieve a sense of pressure position.

2.Advantages for touch-sensitive series whitebaord:
1)relatively accurate positioning
2)easy to operate,donot need specific pen

3.Application field:
it has been widely used in schools at all levels,all kinds of training institutions in military,enterprisesand other industries.

4.Software features:
1)Our software is easy to install,and convenient to operate.
2)Our software has abundant and vivid teaching resources.It provides massive image resources,teaching templet management center,enable teachers to prepare their courseware easily.
3)Our software support bmp,jpg,tif etc. image format,txt,doc,exl,ppt,pdf etc. file format and AVI video format.
4)Our software adopt intelligent recognition technology.It can recognize your handwriting into standard font.Content recognized covers traditional Chinese,simple Chinese,punctution mark,radicals of Chiese characters,english,didits etc.
5)Our software has auto-replay function.All operations of
writing,marking,editing can be played back word by word without any other players.

Hardware features:
1). Environment -friendly, no pollution and radiation, highly-precise orientation with no abrasion and noise, utilize little system resource.
2). Adopting anti-aliasing technology with the horizontal linear processing thus makes it stable and reliable with swift reflection and high resolution thereby your writing is smooth, fluent and clear.
3). Convenient to install and adjustable at any angle with the options of wall-mounted,  mobile floor stand and height adjustable style etc.
4). High-frequency sampling and transporting, quick response with no delay.

Working environment:
.Working Temperature :-10 °C to 50 °C
2).Storage Temperature :-20 °C to 60 °C
3).Working Humidity :20% to 85%
4).Storage Humidity :0% to 95%
5).Illumination Test :Incandescent Lamp (220V,100W) ,
6).Working height above sea level :3,000 meters
7).Working Lifetime :More than 5 years

Standard accessories:
.NHBoard Driver CD
2PCS whiteboard pens
Wall-mounting bracket one set
USB cable line 10 meters
Ink pen 2 PCS(optional)
Mobile Floor Stand(optional)

Specifications for Touch-sensitive Whiteboard
1).Ways of Induction :Resistor Induction
2).Writing Ways :Pen, fingers, or other blunt object
3).Projection Proportion :4 : 3/16:9
4).Resolution :8192 × 8192.
5).Process rate :500 point/second
6).Precision :≤1mm
7).Screen Surface :The hard-coated polyester surface is tear proof, optimized for projection, compatible with dry-erase markers (with MPC surface supported which is optional accessory)and easily cleaned with whiteboard cleaner.
8).Wall Mount Bracket :Wide with six screws and drywall anchors to support a wall-mounted interactive whiteboard.
9).Computer Connection :32"(10m) USB Cable; 25m optional accessory
10).Power Requirement: Power is obtained from the computer directly through the USB cable
11).Mobile Floor Stand :Optional accessory, with 12 different height notches to adjust.
