3G Yagi Antenna
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | Ameison | Place of Origin | China | |
| Model Number | AMXY-3G-16 |
Product Description
3G yagi antenna:
|
Model NO |
AMXY-3G-16 |
|
Electric Spec |
|
|
Frequency rang-MHz |
1920-2170 |
|
Bandwidth -MHz |
250 |
|
Gain -dBi |
16 |
|
element |
15 |
|
beam width -° |
H:30 V:30 |
|
F/B Ratio-dB |
≥16 |
|
VSWR |
≤1.5 |
|
Input Impedance-Ω |
50 |
|
Polarization |
Horizontal or Vertical |
|
Max power -W |
100 |
|
Lightning protection |
DC ground |
|
Connector model |
SMA female or others |
|
Mechanical Specification |
|
|
Size -mm |
590*84*44 |
|
Cable length-m |
1 |
|
Antenna weight-kg |
0.32 |
|
Working Temperature -°c |
-40~60 |
|
Rated Wind Velocity-m/s |
60 |
|
Clamp |
U |
|
Pole diameter -mm |
Φ40~Φ50 |
