(Want Agent in America)integrated Stepper Motor With Motion Controller (Nema 17)

Place of Origin	China
Model Number	stepper motor

integrated stepper motor with built-in motion controller (Nema 17) Nema 17 stepping motor with UIM 24002 integrated stepper drives Nema 17 stepping motor with UIM 24004 integrated stepper driver UIM42-a stepper motor could use a UIM24002 stepper motor driver for building up an integrated stepper motor UIM42-b stepper motor could use a UIM24002 or a UIM24004 stepper motor driver for an integrated stepper motor UIM42-c stepper motor is corresponding to a UIM24004 stepper motor driver You have to consider at least two parameters of a stepper motor to choose the right UIM stepper motor driver for an integrated stepper motor: The Rated Current and the Torque UIM24002 adopt 10-35V DC power supply and supply 0-2 amps settable output current. UIM24004 adopt 12-40V DC power supply and supply 1.5-4 amps adjustable output current. The UIM24004 performs much better than UIM24002, the temperature of UIM24004 after a 8 hours continuous working is about 50 degree Celsius and the UIM24002 could reach about 60 degree Celsius which is among their working environment. The working condition influence a bit on the temperature of the stepper motor driver: If there is a big metal module on your machine for mounting the stepper motor or working with pause, the temperature of the integrated stepper motor will go down. Besides this Parallel port stepper driver, ystepper motor driversou could also use UIM241 Serial port with RS232 interface and UIM242 CANBus networking stepper controllers to build up an integrated stepper motor. Flange is supplied. Further more integrated stepper motor(nema17,nema23,nema34,nema42), stepper controller with RS232 , can bus stepper controller and smart self-pulsing stepper controller and are available. We are finding dealers and agents in contries of North America(USA,Canada etc.) and Latin America(Brazil,Argentian etc.).
