Portable Jaw Crusher

Brand Name	Esong		Place of Origin	China
Model Number	EP

Tire Mobile Crushing Station

Tire mobile crushing station can is a kind of crushing machine mainly used for processing materials in smelting, chemical industry, production of building materials, and power industry, etc.
It is especially suitable for processing the stones used in road building and hydraulic power projects.
Users can adopt different configurations according to categories and sizes of materials, and so on.

Applications and Features of Tire Mobile Crushing Station:
1. Integrated machine set
Integrated machine set is easy to install. This can not only eliminate complicated installation work, but also lower the consumption of materials and working hours.
The rational and compact structure makes the tire mobile crushing machine easy to be stationed.
2. Flexible maneuverability
The tire mobile crushing station has the characteristics of high chassis, narrow body, and small turning radius, which makes it easier to run on the highway, even on uneven ground surfaces in crushing sites, thus saving time and money.
Mobile crushing station can provide more flexible space and reasonable layout configuration for the whole crushing process.
3. Low transportation cost
Tire mobile crushing station can crush the materials on-site, so there is no need to transport the materials to a certain site for crushing. This largely reduces the transportation cost.
In addition, the lengthened machine can send the crushed materials directly into the transport truck.
4. Effective working
Integrative tire mobile crushing station can perform their own duty separately, as well as be configured with other components to meet customers' requirements, such as mobile crushing and mobile screening and so on. This will make the crushing and physical distribution more efficient, and thus minimize the cost.
5. Strong Adaptability and Flexible Configuration
Tire mobile crushing station is suitable for coarse crushing and fine grinding. It can work separately or be configured with other components to meet various requirements.
Diesel generator can not only supply power for this machine, but also supply electricity for the configured parts.
It has reliable performance and is convenient to maintain.

Technical parameters of Tire Mobile Crushing Station:
Table 1


Components	Transportation Parameters	Working Parameters
Crusher EP600X900 Vibrating Feeder Length 3800mm Width 960mm Belt conveyor Standard Length: 9500mm Lengthened Length: 11600mm Width 650mm	Transportation Length L1: 12500mm Transportation Width B1: 2450mm Transportation Height H1: 4000mm Chassis Height H4:1720mm Altitude difference between tires and chassis H5: 380mm (with double shafts) Double tires on each side  Specification 11.00-20 Total weight Standard machine 37650kg Lengthened machine 38000kg	Motor power: 91.5KW Crushing capacity: 70-140T/H Feeding height H3: 4500mm Standard machine Equipment length L2: 13150mm Feeding height H2: 2700mm Lengthened machine Equipment length L2: 15050mm Feeding height H2: 3100mm

Table 2


Components	Transportation Parameters	Working Parameters
Crusher EP600X900 Vibrating Feeder Length 3800mm Width 960mm Diesel generator Model: MP-180-4 Power: 225KVA 180kw Weight: 2400KG Belt conveyor Length: 12600mm Width: 650mm	Transportation Length L1:14000mm Transportation Width B1: 2450mm Transportation Height H1: 4000mm Altitude difference between tires and chassis H5: 380mm Chassis height H4: 1720mm with double shafts Double tires on each side  Specification: 11.00-20 Total weight: 41100kg	Motor power: 93.5KW Crushing capacity: 70-140T/H Feeding height H3: 4500mm Equipment length L2: 16300mm Feeding height H2: 3300

Esong is a professional tire mobile crushing station manufacturer and supplier in China. We are dedicated to manufacturing crushing machines, cement production lines, rolling mill equipment, fertilizer equipment, etc. These mining machines are good in quality and low in prices. They are highly approved by our customers.
Welcome global users to buy our stone crushing machines!
