WZDS Series Biaxial self-synchronization elliptical(linear) same thickness screen

WZDS  Series Biaxial self-synchronization elliptical(linear) same thickness screen

Usage

WZDS Series Biaxial self-synchronization elliptical(linear) same thickness screen are widely used in metallurgy industry such as sinter ore, sintering and palletizing , ore classification in mine industry, classification dehydration and referral, etc. Compare with the other same type products, the screen has larger capability, higher efficiency, more simple structure, more simple control, lower failure and lower cost. They are the first choice for large sintering plant, Pelletizing plant, Concentrator, coal preparation plant, coal washery and also the ideal substitutes of large vibrationg screen for the international project.

Working principle:

The two motors use the shaft to make the eccentric plate on the exciter rotate reversely. The linear or elliptical vibrating made by the eccentric plate on the two axes drives the screen box on the screen base through the isolation system to vibrate linearly or elliptically. After sending the materials into the screen box, the materials are categorized by size on the screen plate in the vibrating process. As the biaxial self-synchronization elliptical(linear) same thickness screen does not use any mandatory synchronization devices to achieve self-synchronization, which makes the structure simple without the complex synchronization devices. It is simple managed, has less separate parts, less failure, less mend, so the cost is lower. It has the advance of short path, few parts little energy cost, save energy, low noise. As screening in the same thickness, the process balances the efficiency and capability, then it has high efficiency and large capability.

Principle and structure feature:

The principle of same thickness screening: WZDS series biaxial self-synchronization elliptical(linear) same thickness screen is near curved surface combined with three parts of screen plate in different angles. The materials on the sieve are reducing when it get through the sieve mesh., the speed of the materials lows down as the lean angle of screen decreases, then to make the thickness of the materials in and out almost the same.

The principle of self-synchronization: without using synchronous transmission and connection devices but two motors in the same parameters to drive the two groups of shaft. In the moment of starting screen simultaneously, the two motors synchronously use the two shafts to make the eccentric plate rotate self-synchronously.
