Cargo Semitrailer With Side Wall / Semi Trailer

Cargo Semitrailer with Side Wall / Semi trailer

Specifications:
1) Dimensions and weight:
A) Nominal dimensions (L x W x H): 13, 000 x 2, 500 x 2, 700mm
B) Platform height: 1, 500mm
C) King pin height: 1, 200mm
D) King pin setting: 1, 200mm from rear face of front bolster
E) Max. Payload: 40, 000kg / 45, 000kg
F) Tare weight: 7, 200kg / 7, 900kg
2) Running system:
A) Suspension system: Leaf spring or airbag suspension
B) Axle: Various axles like BPW, YORK and FUWA with various bearings
C) Tire: Various brands of bias tires or radial tires
D) King pin: Forged steel, 2" or 3.5", welded or bolt-in
E) Landing gear: 24T, 25T etc.
3) Chassis:
A) Provides 8 or 12 retractable type twist locks
B) Main beam: High-tensile steel
C) Surface preparation: Shot blast
D) Painting: Zinc-rich primer and modified urethane topcoat as customers' choices
4) Brake system:
A) Double line air brake system with single air tank, standard connectors on front bolster
B) Optional anti-lock brake system
5) Electrical system: Standard electrical equipment
6) Accessories:
A) Tool box (box only)
B) Spare wheel holder (no spare tires and wheels)

Features:
1) Optional steel side rail
2) Entire chassis shot-blasted
3) Paint system comprising zinc rich primer and urethane topcoat paint
4) Heavy duty construction
5) All major structural steel parts of high-tensile steel
