Thin SMD Low/Medium Frequency Crystal Unit MC146
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | Epson | Place of Origin | China | |
| Model Number | MC146 |
Product Description
Thin SMD Low/Medium Frequency Crystal Unit MC146, Thin SMD Crystal Unit MC146,Quartz Crystal Resonators MC146
Model: MC146
Features:
High-density mounting type SMD of 1.4mm thickness
Small Packing area and light weight
Excellent shock resistance and environmental capability
Most suitable for small communications devices
Specification:
Frequency: 32.768Khz ,75.000Khz
Size: SMD 7.0x1.5x1.4mm
Frequency Tolerance: 20ppm, 50ppm
Load capacitance: 6pf
Operating temp. range: -40C - +85C
Storage temp. range: -55C - +125C
Drive level: 1.0uW
Shunt Capacitance: 0.8pf
Motional capacitance: 1.9pf max
Insulation resistance: 500MO min at DC100V
Aging level: 3.0ppm/year Max at 25C
Packing: Tape and Reel Package , 3000pcs per reel
