H-S420 vertical packing machine/packing machinery/packaging machine

H-S420  vertical packing machine/packing macinery/packaging machine .

1  PLC control with touch panel-step by step instruction

2   Equipped with servo winding system, pneumatic control system.

3  The maximize to improve the whole machine's precision, reliability and stability.

4  Use intellectual temperature controller, the high temperature control to ensure the neat sealing .

5  The perfect automatic alarm safety protection, little waste. This machine completes the whole packing procedure of measuring , feeding , bagging , date printing, charging ( exhausting), products out-putting. counting automatically .

6  Bag type : making pillow bag, vertical gusset bag, hanging bag according to customer's different requires

IIApplication

Its suitable to use in packing the high accuracy and easy fragile material , such as : puffy food , crispy rice , Potato Chips , Snacks , candy , pistachio , sugar , apple slices , dumpling , chocolate , pet food , small wares etc .

Specification

 Item                         Model HS-420 Vertical form-fill-seal machine

Packaging speed       15-90 bag/min

Bag-making size        (W)60-200mm (L)50-300mm

Bag-making type        PillowStand up bagHole punching device

Filling range               Max 1500ml

Max film width            420mm

Film materialPOPP/CPP,POPP/VMCPP,BOPP/PE,PET/VMPET/PE,PET/AL/PE,NY/PE,PET/PET.

Film thickness                      0.04-0.08mm

Air consumption                   0.4m3/min 0.8MPa

Total power/voltage               3KW/220V 50-60Hz

Outside size                         1400×970×1700mm

Gross weight                         450kg
