Tea &Coffee Packaging Machine

Brief Introduction:-

Model: TK-TPY-11CH is the ideal instant tea bag filling and packing machine complete production online especially for refined tea and coffee instant bag with drawn thread and customized label tag.

It is complete with fully auto function as follows:-
- Automatic filling measurement of refined tea leaves
- Automatic insertion and feeding of drawn thread
- Automatic customized label tag attachment
- Pre-program cutting
- With automatic unit counter

Costs effective, single operator, user-friendly and high productivity

Recommendation: For the filling and packing of all type of refined tea, coffee and others.

Technical Data:-

Measurement - Volume metric method
Measuring Scope - 2.5-10ml about 1.505gsm of refined tea leave
Bag Size - Min. 50 x 50mm; Max.65 x 80mm
Label Tag Size - 28mm (W) x 25-30mm (L)
Packing Speed - 30 60 bags per minute
Machine Weight - 450 Kg
Input Power Supply - AC220V 50 Hz
Total Power - 1.6Kw
Main Motor - AC 220V 370W Single Phase 14000rpm
Heater - AC 110V 250W 2 pcs / AC 110V 300W 2 pcs
Central System - About 40W

For more details and vidio presentation,please contact our oversea export office in China!
