heat pipe solar heating system

FOB Price

US$ 699 - 699 / Set

1 Set(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Eusolar		Place of Origin	China
Model Number	EUCLS

Product Description

A 50/50 propylene glycol and water mixture flows from the collectors through a coil of pipe in the solar tank, and then is pumped back through the collectors. The water is warmed by heat exchanger through contacting with pipe. This system is almost the only choice in very cold climates area. When there is no enough solar energy, an electrical or gas element back up will be automatically switched on by controller.

Feature:

Simple installation, no maintenance, easy operation

Suitable for single and multiple solar heating application systems

First choice for extremely cold and questionable water quality areas

Incoming cold water is routed to the storage tank

Porcelain enamel or SUS316L stainless steel storage tank with electrical or gas back up

Double-walled copper coil heat exchangers in storage tank prevent contamination of household water.

Systems Specifications: >>>

A complete system includes three parts: High Pressure Collector, Storage Tank with Cooper Coil, Working Station with controller and Pump

Model	Tank Capacity	Heat pipe or U Pipe Collector		Work Station	Qty (20/40 FCL)
Model	Tank Capacity	Φ58X1800	No.	Work Station	Qty (20/40 FCL)
EUCLS150	150L	Φ58X1800	15 (1 collector of 15 tubes)	A circulating unit system combined by controller and pump station	45/96
EUCLS 200	200L	Φ58X1800	20 (1 collector of 20 tubes)		32/68
EUCLS 250	250L	Φ58X1800	25 (1 collector of 25tubes)		27/56
EUCLS 300	300L	Φ58X1800	30 (1 collector of 30 tubes)		24/50
EUCLS 400	400L	Φ58X1800	20X2 (2 collector of 20 tubes)		19/40
EUCLS 500	500L	Φ58X1800	30x1+20X1 (1 collector of 30 tubes and 1 collector for 20 tubes)		16/36
