THIS CDMA FWT WITH 8 CHANNELS  IS PERFECT QUALITY. IT IS SUITABLE VOIP GATEWAY, PBX, PAY PHONE ,A PHONE AND ETC.

The design of the TLD SX01C-8WAYS(OEM MODULE: YS-X-CALL, YS-X-TERMINAL) FWT is to supply a standard sound phone in the area of the CDMA Cell Network covering.
The interface board of the TLD SX01C-8WAYS FWT supply a clear bond between standard phone or a VOIP GATEWAY or A PBX and CDMA Cell Network it possesses the function of the emulation phone exchanger and supply:
Features:
 ◇    Dialing tone with 450hz
◇    DTMF Dialing
◇    Bell signal
◇    Polarity reversal
◇    The RJ-11 socket which connect the phone or the payment
◇    Antenna socket (FME)
◇    IP usage switch
◇    Working state indicator
◇    Signal Strength indicator
Technical Specifications

CDMA Module Dual band CDMA 2000 1X 800/1900MHZ
 Phone interface：supply RJ-11 Phone Interface
     Hanging voltage:45V  Picking off voltage：30mA/41mA
     Dialing tone Frequency：450Hz
 Antenna interface ：Antenna amplifying 〉1.5DB
Sensitivity 〈 -104DBM
Transmitting power≤3W
 Adapter interface：INPUT：AC 175~260V
OUTPUT：+12V/1000MA
   Operation Circumstance:
Operation temperature：-10℃ ~ 60℃
       Storage temperature：-20℃ ~ 70℃
       Operation humidity：45% —95%
       Atmosphere pressure：86 —106Kpa
        Environment noise：〈 60DB
        Transmitting Power: 2W
        Sensitivity: <-104dbm
        Antenna Amplifying: >1.5db
        Dialing frequency: 450Hz
        Hanging voltage: 45V
        Picking carrent: 30mA/41mA
       Packing:
     ○ Product dimension: L455x W280 x H45mm
     ○ Gift box dimension: L510x W170x H64mm
     ○ G.W: 4.5kg
