Home > Products > Saw Series > Edge Mitre Saw （ZHJ4×8A）
Edge Mitre Saw （ZHJ4×8A）
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Place of Origin | China | |
| Model Number | ZHJ4×8A |
Product Description
ZHJ4×8A Edge Mitre Saw is one of main equipments of plywood
manufacture, the hot pressed plywood plank after edge cutting by mitre
saw, can meet user’s required cutting specifications. ZHJ4×8A Edge Mitre Saw is made up of six parts including lengthwise
feeding conveyor, lengthwise edge mitre saw,lengthwise output
conveyor,turning conveyor, widthwise mitre saw, and widthwise output conveyor. The equipment has the advantage of high efficiency and high
speed in slick cutting, it is the ideal equipment in plywood production.
Technical Parameter of Edge Mitre Saw:
|
ZHJ4×8A.1Lengthwise feeding conveyor |
|
|
Conveyor length（mm） |
5789 |
|
Conveying width（mm） |
915-1380 |
|
Conveying speed（m/min） |
70 |
|
Motor |
YMT112-48,1：8，0.75Kw |
|
ZHJ4×8A.2Lengthwise edge mitre saw |
|
|
Sawing size（mm） |
915-1220 |
|
Max.sawing thickness（mm） |
30 |
|
Saw blade diameter（mm） |
Φ 305 |
|
Saw blade speed(rpm) |
6800 |
|
Feeding speed（m/min） |
25-70 |
|
Saw blade motor |
Y1325S1-2 5.5kw 2900rpm |
|
Feeding motor |
MBW40-Y4-C5 |
|
ZHJ4×8A.3Lengthwise output conveyor |
|
|
Conveying speed（m/min） |
25-70 |
|
Conveying width（mm） |
915-1220 |
|
Drive way |
by lengthwise saw |
|
ZHJ4×8A.4Turning conveyor |
|
|
Lengthwise roller speed（m/min） |
25.37-71.03 |
|
Widthwise chain feeding speed（m/min） |
23.84-66.75 |
|
Lengthwise roller transmission |
driven by lengthwise output conveyor |
|
Widthwise chain transmissions |
driven by widthwis saw through electro-magnetic clutch |
|
ZHJ4×8A.5Widthwise mitre saw |
|
|
Sawing size（mm） |
1830－2440 |
|
Max.sawing thickness（mm） |
30 |
|
Saw blade diameter（mm） |
Φ 305 |
|
Saw blade speed（rpm） |
6800 |
|
Saw feeding speed（m/min） |
25－70 |
|
Motor |
|
|
Saw blade motor |
Y112M-2 4KW 2800rpm |
|
Feeding motor |
YMT180-4A-XWD40-4 1：9 |
|
ZHJ4×8A.6Widthwise output conveyor |
|
|
Conveying speed （m/min） |
25－70 |
|
Transmission way |
driven by widthwise saw |
