tipper truck

specification of the tipper truck

Cabin: HW70 Standard Cab (two seats, no bed), HW76 Lengthened Cab (two seats, one bed), all with four point support fully floating suspension+ shock absorber and AC.

Driving type: 8*4.

Wheelbase:
Gross Vehicle Weight: 40000KG
Vehicle dead weight: 15000KG
Loading capacity: 25000KG
Engine: SINOTRUK brand
Displacement(L): 9.726
EURO II Horse power ranges: 266hp, 290hp, 336hp, 371hp and 410hp
Engine type: 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and intercooling
EURO III Horse power ranges: 266hp, 290hp, 336hp, 375hp and 410hp
Engine type: high pressure common rail type, 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and intercooling

Transmission: HW9, HW16, FULLER9, ZF9, FULLER8, ZF6

Propeller shaft: Double universal joint propeller shaft with gear-shaped coupling flange

Clutch: 420 for 336hp and below(Single-plate dry coil-spring clutch, hydraulically operating with air assistance), 430 diaphragm clutch for 371hp and above

Front axle: HW08, Steering with doubleT-cross section beam

Rear axle: HC16, Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles.

Steering gear: ZF power steering, modol ZF8098, hydraulic steering with power assitance

Brake system
Service brake: Dual circuit compressed air brake
Parking brake(emergency brake): Spring energy, compressed air operating on rear wheels
Auxiliary brake: Engine exhaust brake
ABS: WABCO, imported from Germany

Wheels and tyres
Rims: 8.5-20, 10 hole-steel Tyres: 12.00-20
Option: 12.00R20, 12.00-22.5, 12.00R22.5, 12.00R24
