Mill Finished 90 Degree Anodised Aluminium Angle for Solar Mounting System And Solar Panel
- T/T L/C D/P D/A
- 7 days
You May Like
-
U Shaped Aluminum Extrusion Medical Equipment Parts , Anodized 6000 Series Aluminum Profiles
-
Industrial Hollow Aluminum Extrusion Profiles , Silver Anodized Aluminium Triple Parts
-
6063 - T5 Custom Aluminum Extrusions Profiles for Electric Bike Battery Case Frame
-
Extruded Anodized Finish Aluminium C Channel for Curtain Track System OEM
-
Black Anodized Aluminum Slide Track , Ceiling Mounted Curtain Track 20 X 25 Mm
-
30 MM 6063 T4 / T6 Anodized LED Strip Aluminium Extrusion for 24 Watt Panel Light
Product Details
| Brand Name | KaiLun | Place of Origin | China | |
| Model Number | KL-SF2132 |
Product Description
Certification:ISO/TS16949:2009
Mill Finished 90 Degree Aluminium Angle Corner Key for Solar Mounting System and Solar Panel
Product Description:
1. Name:?aluminium angle corner key
2. Size: 47.7*47.7MM
3. Weight:0.81kg/m
5. Material: 6005, 6063, 6061, etc.
6. Coating Thickness: 10 - 15 um
7. Length:?as?customer's?requirement
8. Standard:?EN 755,CB/T 6892,SGS
9. Certification: ISO/TS16949 : 2009
10. Deep Process: cutting,drilling,punching,etc
Two types:
(1) 90°-Angle
(2) 45° -Angle
Suface Treatment:
(1). Anodizing:(Clear,silver,golden,bronze,other muiticolar.)
(2). Electrophoresis
(3). Powder coating,mill finish,PVDF,sandblasting,etc
Package:
Foam paper and carton box package, craft paper package, plastic film and the plastic wrap.
All the specification and packing details can according to customer's request
Specifications:
|
Business?type: |
Manufacturer |
|
Standard: |
GB?5237-2008 / En 755.2 |
|
Product?series: |
Aluminium?profile?for angle parts |
|
Surface?treatment: |
Anodizing,?Powder?coating,?electrophoresis,?wooden?finish |
|
Packing: |
Kraft?paper,?EPE?foam,?Shrink?film,?Composite?paper |
|
Payment?term: |
T/T,?L/C?at?sight |
|
Specification: |
A.?Alloy code 6063,?6060,?6061,?6005, 6082 |
|
B.?State:?T4 / T5 / T6 |
|
|
C.?Length:?1m-7m |
|
|
D.?Normal?Anodizing?thickness:?8-15?micro |
|
|
E.?Normal?powder?coating?thickness:?60-100?micro |
|
|
F.?Tensile?strength:?≥?160?mpa |
|
|
G.?Yield?strength:?≥?110?mpa |
|
|
H.?Extensibility:?≥?8% |
|
|
I.???Hardness(HW):?≥?8 |
|
|
Normal?order?process: |
1.?Confirm?the?drawings,?colors?and?price; |
1) Chemical composition
| Alloy | ? ?Si | ? ?Fe | ? ? Cu | ? Mn | ? ? Mg | ? ? ? Cr | ? Zn | ? Ti | ?impurity | ? Al |
| 6063 | ? 0.2 | ? 0.35 | ? ? 0.1 | ?0.1 | 0.45-0.9 | ? ? ?0.1 | ? 0.1 | ?0.1 | ? 0.15 | Rest |
| 6061 | ?0.4-0.8 | ? 0.7 | 0.15-0.4 | ?0.15 | 0.8-1.2 | 0.04-0.35 | ?0.25 | 0.15 | ? 0.15 | Rest |
| 6060 | ?0.3-0.6 | 0.1-0.3 | ? ? 0.1 | ?0.1 | 0.35-0.6 | ? ? ? ?- | ?0.15 | ?0.1 | ? 0.15 | Rest |
| 6005 | ?0.6-0.9 | ? 0.35 | ? ? 0.1 | ?0.1 | 0.4-0.6 | ? ? ?0.1 | ? 0.1 | ?0.1 | ? 0.15 | Rest |
2) Mechanical property
| ?Alloy | ? Temper | ? ? ?Tensile strength | ? ? Yield strength | ? ?Elongation |
| 6063 | ? ? ? T5 | ? ? ? ? ?≥160Mpa | ? ? ? ?≥110Mpa | ? ? ??≥8% |
| ? ? ? T6 | ? ? ? ? ?≥205Mpa | ? ? ? ?≥180Mpa | ? ? ??≥8% | |
| ?6061 | ? ? ? T6 | ? ? ? ? ?≥265Mpa | ? ? ? ?≥245Mpa | ? ? ??≥8% |
