Indoor high-voltage isolation switch

Uses: GN30-12 indoor high-voltage switches for rated isolation voltage 12kV, the three-phase AC 50Hz indoor installations, as the power system in case of no-load voltage breaking, with closed circuit. Especially suitable for the installation of high voltage switchboard, high voltage switchboard so that the compact, simple, small footprint, improve the reliability of its security. The series switches can be isolated CS6- type actuator operation can also be designed actuator.

Structural characteristics: GN30-12 isolation switch is a rotating touch a new type of knife-isolation switch, the main switch by the two groups in fixed insulators up and down the two chassis switches on the surface, the two face up and down between the switch from fixed to the shelf The partition separately entirely through touch-rotating knife, so as to achieve the closing of the switch and the sub-gate. Since the static contact were switchgear installed on the upper and lower surface of the two to live and not live in the part of the switch completely separated from the cabinet in order to guarantee the safety of maintenance personnel.
