supply for large-scale car-style hot melt marking machine / self-marking machine / Road Marking

1. Engine: 42HP electric start water-cooled inline four-cylinder low-noise environment-friendly diesel engines, with water temperature, voltage, oil shows, the maximum speed of 3000 r / min. Fuel tank capacity 60L.

2. Drive system: imported with automatic braking devices type continuously variable hydraulic system (HTS), forward, backward and stop easy to use.

3. Drive speed: forward 0-22Km / h; back :0-12Km / h. Maximum climbing ability: 15 °.

4. Heating method: conducting oil heating, heat more evenly, more secure, more environmentally.

5. Glass beads spraying system: synchronization with the coating of glass beads spraying system to ensure that the beads spread more evenly and more savings.

6. Crossed Dipper: left (or right) side configuration two-or one-way hydraulic control variable (concussion Dipper, Dipper closed flat line, flat line open bucket) bucket line type insulation, which can draw double-Shi solid line or one-way. Board structure for the import of high temperature (2000 ) antioxidant special steel plate is not deformed by a better stability after stamping. Special alloy steel substrate for working pneumatic scraping structure deposited. Imported knife landing hard tungsten alloy segment. The Dipper -precision production technology to ensure that their sensor, better wear resistance and solidity, the draw raised marking more orderly shape, the bottom line of the edge of a collimator, a perfect head. Dipper -line standard 150mm (size of the remaining requirements can be based on user configuration).

7. Electronic control: set up two types of shocks to each other line of the peace line independent interface, the interface standards set up a wide range of spacing, the realization of intelligent control of micro-electronics. When shocks can be classified according to the needs of the user can adjust personalized Bump Bump length and spacing, the number of bumping and bump height can be adjusted according to user needs at any time, raised the standard height of 3-7mm.

Weight and size of the machine: 3700mm (length) × 1600mm (width) × 1800mm (high) 2100kg
