2in 2out Max Capacity 96cores In-line Fiber Optic Splice Closure

Place of Origin	China

Perfect Water & Dust Proof Horizontal Fiber Optic Splice Closure (GJSW-404) Basic Info Model NO.:GJSW-404Working Life:25 Years Specification:?CE, ISO, TLSCable Diameter:10mm~25mm Weight::3.5kg Number of Cable :2in &2out Dimension:460mmX180mmX108mm Sealing Method:Mechanical Seal and Sticky Cincture SealMax Capacity:12coresx5=60 Cores;24coresx4=96 Cores(Non-Ribbon )Product Description?1. The Fiber Optic Splice Closure (FOSC) is widely used for connecting of optic cables. It can be installed aerial, buried/underground and wall mounting for network of direct fiber connection or branch fiber connection.? ?2.The case of Fiber Optic Splice Closure (FOSC) is made of high quality Polycarbonate (PC) to make sure good performance of anti-aging and anti-erosion against acid and alkali salt. The reliable mechanical structure of the FOSC case provides good performance of resisting wild environment, intensive climate changes and serious working environment, meanwhile it gives excellent waterproof and dustproof.? ?3.The metal fittings of the Fiber Optic Splice Closure (FOSC) are made from high-quality stainless steel to resist erosion perfectly.? ?4.Easy to open, and it can be opened and used repeatedly.Technical DataStandard complied withYD/T814.1-2004Number of cable port2in &2outCable Diameter7mm~18mmMax Capacity12coresX5=60 cores;? 24coresX4=96 coresSealing methodSticky CinctureDimension460mm×180mm×108mmWeight3.5kgWorking life25 yearsEnvironment temperature?-40~+65?(degree centigrade)Atmospheric pressure70~106kPaSealing Performance?Inflation pressure100kPa/24hTension800N/1min?Wafering2000N/100mm?Impact1m/1kg Steel ball / three timesBending150N/±45°10 /cyclesTorsion50N.m/+90°10 /cycles?Insulated Resistance2×104MΩ/500VCompression strength15kV/1min/10mA
