Coated Panel Car Spray Booth Air Flow Electric Controlled With Heat Recovery System
Negotiable
/ Piece
1 Piece(Min.Order)
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Turbo Fan Small Spray Paint Booth Prep Station Eco Friendly CE TUV Certification
-
LED Lights Turbo Fan Custom Paint Prep Station , Auto Body Prep Station
-
Industrial Lacquer Spray Booth , Spray Bake Booth For Vehicle Painting Drying
-
Outdoor Bus / Truck Spray Booth , Large Paint Booth CE TUV Certification
-
20 Meters Side Draft Truck Spray Booth Equipment Lifter LED Light Siemens Motor
-
Combined Inner Ramp Commercial Paint Booth Coating Full Grilles Energy Saving
Product Details
| Brand Name | Baoyues | Place of Origin | China | |
| Model Number | BY-8 |
Product Description
Certification:CE, TUV
Coated Panel Car Spray Booth Air Flow Electric Controlled With Heat Recovery System
Features
1. With heat recuperation?system, energy save and more efficiency.
2. 0.6mm coated?steel with rock wool inside for wall panel.
3. Quality brand name turbo fans, directly?drive type
4. Riello RG5S diesel burner with a heating productivity of 260000Kcal/h
5. Pneumatic damper for spraying to baking cycle.
6. Double layer heat exchanger.
7. Siemens motors.
8. Electric damper for intake and exhaust, control the air flow.
Advantage
In painting, outside fresh air comes into the heating generators through the pre-filter system, and enters into the plenum, then filtered by ceiling filter and into the both which brings clean,
symmetrical and steady-going down airflow for spraying,After painting, Hot air goes from heating
generators to plenum, then enters room after filtered by ceiling filter, providing heat that is necessary for baking of cars surface. In the meantime, heat recuperation system?start working,energy save and temperature raise fast. Afterwards, the air with little benzene will be released to the atmosphere after being filtered twice by the exhaust air filter.
| Item | Detailed Specification | |||||||
| Inside dimension | 7000×4000×2800 mm (L×W×H) | |||||||
| Outside dimension | 7120×5520×3750mm (L×W×H) | |||||||
| Front door | Folding door, 3 folds, 3000×2750 mm (W×H), without frame, square window frame, orange colour, door head and two batten on both sides white colour, with safety escape door lock. | |||||||
| Emergency door | 1 units, 800×2000mm (W×H), colour: white, with safety escape door lock. | |||||||
| Basement | Galvanized steel assemble, 350mm high, galvanized steel bending support, full grilles made by flat bar 30×5 and twisted steel, galvanized, 3 ramps, 900×2500mm/pc, silver colour. | |||||||
| Wall panel | Thickness: 60mm, both sides covered by coated steel, thickness 0.6mm, with rock wool inside, colour: white. | |||||||
| Light | Ceiling Lights: 8Units×4Pcs=32Pcs×36W, both sides lights: 7Units×4Pcs=28Pcs×36W, back side lights: 4Units×4Pcs=16Pcs×36W, LED light tube. | |||||||
| Generator cabinet | Intake from back upper, exhaust from rear upper, galvanized steel frame; white powder coated panel covered, filled with heat preservation material PU inside. | |||||||
| Intake and Exhaust system | Inlet: 1×7.5KW turbo fan, Siemens motor, air capacity for each fan: 25000m3/h, electric damper. | |||||||
| Outlet: 1×7.5KW turbo fan, Siemens motor, air capacity for each fan: 25000m3/h, electric damper. | ||||||||
| Heating system | Italy RIELLO RG5S diesel burner, double layer stainless steel heat exchanger, pneumatic damper actuates from spraying to baking cycle. Max. heating productivity: 260000kcal/h, with heat recovery system. | |||||||
| Purification system | Pre-filter (pocket type), ceiling filter, fibreglass filter, activated carbon filter (pocket type) | |||||||
| Roof | 50mm rock wool panel. | |||||||
| Control system | Spraying, heat spraying, baking, time setting, lighting switch, failure indicator, thermostat, power supply switch, emergency stop, pressure gauge, all motors reduced-voltage starting. | |||||||
| Total power | 17KW (Power supply 1×220V, 3×380V, 50HZ) | |||||||
