Middle Door High Precision Outside Paint Booth , Bus Spray Booth Rental

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Baoyues		Place of Origin	China
Model Number	BY-15-5

Product Description

Delivery Time:10-15 working days
Certification:CE, TUV

Middle Door High Precision Outside Paint Booth , Bus Spray Booth Rental

Features

1. 0.476mm color steel with EPS inside for wall panel.

2. Quality brand name turbo fan,with air capacity of 30000m 3/h

3. Pneumatic damper for spraying to baking cycle.

4. All panels are tongue and groove interlock structure

5. Control panel and other electric components can be purchased separately

Advantage

In painting, outside fresh air comes into the heating generators through the pre-filter system, and enters into the plenum, then filtered by ceiling filter and into the both which brings clean,

symmetrical and steady-going down airflow for spraying, After painting, tot air goes from heating

generators to plenum, then enters room after filtered by ceiling filter, providing heat that is necessary for baking of bus?surface. Afterwards, the air with little benzene will be released to the atmosphere after being filtered twice by the exhaust air filter

Item	Detailed Specification
Inside dimension	15000×5000×5000 mm (L×W×H)
Outside dimension	15140×7940×5600 mm (L×W×H)
Front door (3units)	Folding door, 4 folds, 4000×4500 mm (W×H), galvanized steel frame, with polystyrene(EPS) inside. (One unit in the front, blue color, one unit in 9m to separate the booth into two parts: 9m booth and 6m booth, white color, another one on the back side, white color.), with marks on front and back side.
Emergency door	2 units, 800×2000mm (W×H), colour: white.
Basement	Without basement, exhaust from two side walls.
Wall panel	Thickness: 70mm, width: 1150mm, tongue and groove structure, 0.426mm colour steel with EPS insulation inside, colour: white.
Light	Ceiling Lights: 18Units×4Pcs=72Pcs×36W, side light: 12Units×2Pcs=24Pcs×36W, without light tube, you put the LED light at site, lighting box are powered coated.
Generator cabinet	Intake from side upper, exhaust from rear upper, quadrate steel frame; white coated steel outside covered, galvanized steel inside, filled with heat preservation material in the middle.
Intake and Exhaust system (2 sets)	Inlet: 2 units, in total 2×11KW turbo fans, air capacity for each fan: 30000m /h.
	Outlet: 4 units, in total 4×5.5KW turbo fans, air capacity for each fan: 18000m /h.
Heating system (2 sets)	2 units RIELLO G20 diesel burners, stainless steel heat exchanger, pneumatic damper actuates from spraying to baking cycle. Max. heating productivity: 200000kcal/h, maximum temperature: 80 ℃.
Purification system	Pre-filter(pocket), ceiling filter, fibreglass filter, activated carbon filter (pocket).
Roof	Galvanized steel
Control system	Spraying, heat spraying, baking, time setting, lighting switch, failure indicator, thermostat, power supply switch, emergency stop, temperature limit controller, hours meter. All motors are reduced- voltage start, Romania language on the control panel.
Total power	48KW(powder supply:1×220V, 3×380V,50HZ)
