gsm car alarm with gps tracker

1. Apply to protect all type of cars, trucks, taxi, jeeps as well as other automobiles.

2. With Chinese/English/Russian/Czech/Spanish/ Turkish voice reminder

3. Friendly human voice reminder. The user needn' t memorize any command to

operate the system..

4. Remote open/close car door and trunk release.

5. Remote arm/disarm

6. Any trigger will auto-dial the preset phone No. and send SMS.

7. Enquiry the status of your car by any phone.

8. No distance limit to control your cars by any phone or SMS.

9. Remote police alert/monitor/oil cut-off/power off/voice frightening.

10. Can activate/deactive car running.

11. Can prohibit/permit telephone alarm.

12. With hidden emergency button, it can send help signal quietly.

13. With backup battery.

14. With hicker memory and safety reminder.

15. Can start car engine and air conditioner by remoter, phone or SMS to create a comfortable driving environment.

16. Car mobile and GSM location

17. Metal case and hopping code remoter.

18. With GPS function.

Basic components

1 Mainframe

1 GSM antenna

2 remote controls

1 GPS antenna

1 dialer

1 shock sensor

1 siren

1 speaker

1 relay

1 emergency help switch

1 LED, 1 microphone

1 bundle of output wire (12 holes)

1 bundle of input wire (10 holes)

1 bundle of input wire (6 holes)

1 bundle of start connection wire (4 holes)

1 operating instruction

1 bundle of fastening wire

Specification

*Mainframe

Working Voltage: 12V

Static Current (with GSM Module): 40mA -60 mA

Arm/Disarm Working Frequency: 400MHz-433HMz

* Input Checking Voltage

Door: 0V

Key: 12V

Foot Brake: 12V

*GSM Module

Frequency: GSM 900MHz/1800MHz/850Mhz/1900Mhz

Voltage of Serial Interface: 2.8V

Stand-by Current: 11-25mA

Static Current: 4mA

* Remote Control

Working Voltage: 12V (1 A27 12V dry battery)

Working Frequency: 400MHz-433HMz

Control Distance: 20-100M

Static Current: 0mA

*Working Conditions

Mainframe

Storage Temp.: -30℃-85℃

Working Temp.: -20℃-6\75℃

Working Humidity: 25% — 95%

Accessory

Storage Temp.: -40℃-100℃

Working Temp.: -20℃-85℃

Working Humidity: 25% — 95%

* Size of the Mainframe

145MM *104 MM *36MM
