Air Driven Pneumatic Diaphragm Pump Aluminium Alloy For Conveying
- 0 Unit / Units per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Cast Iron Pneumatic Diaphragm Pump , Dual Diaphragm Air Pump With High Suction Head
-
Compressed Air Powered Pneumatic Diaphragm Pump For Toxic Liquid Transport
-
Cast Iron Horizontal Multistage Centrifugal Pump For Clear Water Supply
-
Low Temperature Horizontal Water Suction Pump Multistage For Urban Project
-
Stable Running Multistage Submersible Pump , Industrial Centrifugal Pumps
-
High Performance Horizontal Multistage Centrifugal Pump For Drainage Works
Product Details
| Brand Name | AOLIPUMP | Place of Origin | China | |
| Model Number | QBY |
Product Description
Certification:ISO/WSC/CE/SGS
Conveying Machinery Pneumatic Diaphragm Pump Material In Aluminium Alloy
Product Description
QBY Air Operated Pneumatic Diaphragm Pump
QBY pneumatic diaphragm pump, diameter: ￠10mm(3/8"), ￠15mm(1/2"), ￠25mm(1"). ￠40mm(1 1/2"), ￠50mm(2"), ￠65mm(2 1/2"), ￠80mm(3"), ￠100mm(4"). Materials: AL alloy, cast iron, stainless steel. The diaphragm pump seal materials: Neoprene, Buna-U, Rubber, Viton, Teflon.
Advantages:
1. No need of lead water, it can be used as self-sucking pump, dive pump, submersible pump, slurry pump.
2. Wide range of diaphragm materials: neoprene, fluoride rubber, Buna-N rubber and Teflon.
3. QBY air diaphragm pump not only can exhaust the flow liquid, but also can convey some uneasy flowed medium.
Structure Drawing:
Diamension drawing-Model:
Installation Method:
System connection Schematic Diagram:
Materials:
| Model | Materials | ||||
| ZI104 | 1crl8Ni9Ti | Ht200 | PP | F46(EFD),PO | |
| QBY-10 | Yes | Yes | Yes | Yes | No |
| QBY-15 | Yes | Yes | Yes | Yes | No |
| QBY-25 | Yes | Yes | Yes | Yes | Yes |
| QBY-40 | Yes | Yes | Yes | Yes | Yes |
| QBY-50 | Yes | Yes | Yes | Yes | Yes |
| QBY-65 | Yes | Yes | Yes | No | Yes |
| QBY-80 | Yes | Yes | Yes | No | No |
| QBY-100 | Yes | Yes | Yes | No | No |
Parameters data:
| Model | Discharge (m3/h) |
Head (m) |
Exit pressure (kgf/cm) |
Sucked lift (m) |
Max grain Dia (mm) |
Max pressure (kgf/cm) |
consumption Max air (m/min) |
Diaphragm diameter (m/min) |
Weight (kg) |
| QBY-10 | 0-0.8 | 0-50 | 6 | 5 | 1 | 7 | 0.3 | 140 | 7 |
| QBY-15 | 0-1 | 0-50 | 6 | 5 | 1 | 7 | 0.3 | 140 | 7 |
| QBY-25 | 0-2.4 | 0-50 | 6 | 7 | 2.5 | 7 | 0.6 | 230 | 20 |
| QBY-40 | 0-8 | 0-50 | 6 | 7 | 4.5 | 7 | 0.6 | 230 | 24 |
| QBY-50 | 0-15 | 0-50 | 6 | 7 | 8 | 7 | 0.9 | 340 | 50 |
| QBY-65 | 0-16 | 0-50 | 6 | 7 | 8 | 7 | 0.9 | 340 | 56 |
| QBY-80 | 0-28 | 0-50 | 6 | 7 | 10 | 7 | 1.5 | 450 | 70 |
| QBY-100 | 0-30 | 0-50 | 6 | 7 | 10 | 7 | 1.5 | 450 | 78 |
** Providing more details about your requirement such as flow, head, motor, medium and the like, you will get more correct products and price.
·"Save every cent for customers" is the content of our customer service by reducing the service and maintenance costs of customers as much as possible while providing careful and high-quality service.
