Home > Products > Optical Fiber Patch Cord > LC Short Boot Data Centre Optical Fiber Patch Cord OM3 Duplex Aqua 2.0mm 2 Meters
LC Short Boot Data Centre Optical Fiber Patch Cord OM3 Duplex Aqua 2.0mm 2 Meters
Negotiable
/ Kilogram
1 Kilogram(Min.Order)
- 0 Kilogram / Kilograms per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Laser Photodiodes Indium Phosphide Wafers Single or Double Side Polished
-
PIC Laser Photodiodes Indium Phosphide Wafers - Centered Cubic Crystal Structure
-
Om3 PC ST - ST Fiber Optic Jumper 2.0MM Duplex LSZH Multimode Patch Cable
-
Orange SC - SC Fiber Patch Cord Duplex , Multimode Outside Plant Fiber Optic Cable
-
3.0MM Optical Fiber Patch Cord Duplex Orange SC FC Patch Cord LSZH Plastic
-
OFNP Fiber Optic Pigtail Single Mode 9 / 125 0.9mm SC Fiber Patch Cord
Product Details
| Brand Name | FOMS/OEM | Place of Origin | China | |
| Model Number | FOMS |
Product Description
Certification:RoHS/SGS
LC Short Boot Data Centre Patch Cords OM3 Duplex Aqua 2.0mm 2 Meters LSZH
Descriptions:
Our premium data centre patch cords are designed for low loss data centre applications. They provide flexible interconnection to active equipment, passive optical devices and cross-connects. Our patch cords are terminated with premium grade zirconia ferrule connectors which help assure high transmission quality and low optical power loss.
Features:
Premium Low Loss optical performance to meet tight data centre power budgets New flexible boot allows connection in compact spaces Optimised LC and SC connector types Standard and Reduced Bend Sensitivity OM3, OM4 and OS2 Fibre types Available in standard and custom lengths IEC, EIA/TIA or Telecordia compliant RoHS materials, REACH and SvHC compliantApplications:
Data Centres High Bandwidth Ethernet and Fibre Channel Storage Area Networks (SANs) Any critical networkSpecifications:
| Parameter | Unit | FC,SC,LC/Armoured fiber patch cord | ST,MU | MT-RJ,MPO | E2000 | ||||||||||||
| SM | MM | SM | MM | SM | MM | SM | |||||||||||
| PC | UPC | APC | PC | PC | UPC | PC | PC | UPC | PC | PC | APC | ||||||
| Insertion loss(typical) | dB | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.3 | ||||
| Return loss | dB | ≥45 | ≥50 | ≥60 | ≥30 | ≥50 | ≥50 | ≥30 | ≥45 | ≥50 | ≥35 | ≥55 | ≥75 | ||||
| Operating wavelength | Nm | 1310,1510 | |||||||||||||||
| Exchangeability | dB | ≤0.2 | |||||||||||||||
| Vibration | dB | ≤0.2 | |||||||||||||||
| Operating temperature | ? | -40~75 | |||||||||||||||
| Storage temperature | ? | -40~85 | |||||||||||||||
| Cable diameter | ? | 0.9mm,2.0mm,3.0mm | 0.9mm,2.0mm,3.0mm | 0.9mm,2.0mm,3.0mm | 0.9mm,3.0mm | ||||||||||||
Order Informations:
| Item | Type |
| Fiber optic connector | LC,FC,SC,ST,MTRJ,JU,DIN,D4,MPO,SMA,E2000 |
| Polishing | PC,UPC,APC |
| Fiber optic cable model | Singlemode: g652d, g655, g657a |
| Multimode: 62.5/125(OM1), 50/125(OM2), OM3, OM4 | |
| Fiber optical cable diameter | 0.6mm, 0.9mm, 1.6mm, 2.0mm, 2.4mm, 3.0mm |
| Fiber brand | Corning, YOFC |
| Fiber Cores | simplex, duplex, multicore (4-48cores) |
| Fiber optic patch cord length | 0.5m to 1km are available |
| Fiber optic cable type | Indoor, ribbon, bunch, armored, waterproof, outdoor |
