VERTICAL DRILLING MACHINE

WD-32 VERTICAL DRILLING MACHINE Principal Technical Parameter
1. Max. diameter capacity                         (Iron)32mm

                                               (Steel)25mm
2 .Distance from axis of spindle to generating line of column    300mm
3 .Max. distance from spindle nose to working surface         800mm
4 .Max. distance from spindle nose to working surface of baseplate        1225mm
5. Max. travel of spindle box                              270mm
6 .Max. travel of spindle                                 150mm
7 .Max. travel of table bracket                             550mm
8 .Taper of spindle                                  Morse No. 4
9. Step of spindle speed                                     12
10 .Range of spindle speed(50Hz)         78,105,160,235,315,400,480,555,840,1230,1650,2500  r/min
11. Effective working area of table            π×1902   (m㎡)
12. Effective working area of baseplate (L×b)           360*420mm
13. Turn angle of spindle box                            ±180°
14. Turn angle of table and bracket                        ±180°
15. 2-speeds motor's       power                 1/1.3/1.7  kW
     YD112-8/6/4    speed (50Hz)   705   /940/1440 r/min
16. Max. overall dimensions (l×b×h)    505mm×880mm×1910mm
17. Weight of the machine (gross weight)                     520kg

                       (net weight)                      390kg
