PID Control Function Industrial Inverter VF Control , Invt Inverter Chf100A

Brand Name	INVT		Place of Origin	China
Model Number	CHF100A series

Certification:CE, TUV

PID Control Function Industrial Inverter VF Control , Invt Inverter Chf100A

Brief Introduction

CHF100A series high performance universal inverter is the enhanced edition of CHF series, which is combined the advantage of CHF100 & CHE100. It adopts the DSP control system supplies sensorless vector control and V/f control. The performance is more perfect and stable. It is widely applied in Pump & Fan and some applications with high speed control accuracy, rapid torque response and high performance at low frequency.

Features

Three control modes: without PG vector (SVC); V/F control; and torque control. Starting torque: without PG vector control: 0.5Hz/150% (SVC); 18.5kW-90kW inverter built-in DC reactor to improve input power factor and increaseoverall efficiency and stability; Internal brake unit with every specification 0.75-15kW, so that the braking resister can be connected directlyfor a quick stop; 16-steps simple PLC, multi-speed control, and PID control; Supporting multi-frequency installation methods: digital setup, analog quantity setup, PID setup, and communication setup; Supports starting and stopping DC brake; The input and output terminals may be freely programmed, so users may combine a variety of operating modes as needed; Equipped with jump frequency control which prevents mechanical resonance and makes the system more stable and reliable; Equipped with instantaneous power failure non-outage capability; Equipped with sleep-wake delay installation capability; Equipped with over-torque detection; Variety of maximum frequency setting source options; Equipped with a bidirectional shift key , which enables users to use the shift key to view real-time parameters; Rotation speed tracking re-start function: allowing rotating machinery to be started smoothly and without any shocks; QUICK/JOG function: users can freely define multi-functional shortcut keys, and by setting up these parameters users can quickly browse different function codes of modified which are different from default values; Equipped with automatic voltage adjustment function, which can effectively resolve problems with high-power motors low-frequency vibrations; Equipped with vibration suppression; Offering a variety of fault protection functions: over-current, over-voltage, under-voltage, over-temperature, phase-failure, overload, etc.

Specifications

I/O Features	Input Voltage Range	380/220V±15%
Input Frequency Range	47～63Hz
Output Voltage Range	0～rated input voltage
Output Frequency Range	0～400Hz
I/O Terminals	Input Terminals	Programmable DI:7,1high speed pulse; Programmable AI:2,AI1:-10V～10V;AI2:0～10V or 0～20mA.
Output Terminals	Programmable open collector output:1(open collector or high speed pulse output selectable); Programmable relay output:2; Programmable AI:2,0/4～20mA or 0～10V selectable.
Communication Terminals	Provide RS485 communication interface,adopt Modbus-RTU communication mide.
Control Function	Control Mode	V/F control, sensorless vector control(SVC)
Speed Adjusting Range	1:100(SVC)
Overload Capacity	150% rated current 60s, 180% rated current 10s.
Frequency Reference Source	Keypad, analog input, HDI, serial communication, multi-step speed, simple PLC and PID. The combination of multi-modes and the switch between different modes can be realized.
Other Functions	1)????? Traverse Control Function 2)????? PID Control Function 3)????? Simple PLC, Multi-Steps Speed Control Function: 16 steps speed can be set. 4)????? None-Stop when instantaneous power off. 5)????? Speed Trace Function: Smoothly start the running motor. 6)????? Automatic Voltage Regulation Function(AVR) 7)????? Up to 23 fault protections: over current, over voltage, over temperature, phase failure, overload etc.
Man-machine Interface	LED Display	Can display: setting frequency, output frequency, output voltage, output current
