Small-capacity Test / Integrated Design Impulse Voltage Generator Set
- T/T L/C D/P D/A
- 7 days
You May Like
-
Impulse Voltage Generator Applicable for testing of 220kv -7200 kV
-
Impulse Voltage Generator test the insulation of electrical equipment
-
Magnetic level gauge used to measure and control liquid level In corrosive liquid tanks
-
Explosion protection Liquid Level Meter , Industrial Measuring Instruments
-
High stability Magnetic level gauge , analog or digital output manner
-
IP66 / IP67 Magnetic level gauge , Industrial Measuring Instruments
Product Details
| Brand Name | HIWING | Place of Origin | China | |
| Model Number | CDYX series |
Product Description
Small-capacity Test / Integrated Design Impulse Voltage Generator Set
Impulse voltage generators are electrical apparatuses which produce lightning, chopping waves, crest, switching impulse for atmospheric over voltage test on HV apparatus, switching surge tests and product testing of HV apparatus manufacturers.
? CDYX-20 impulse voltage generator is featured by integrated design, small size, light weight, easy ? ? ?operation, flexibility and mobility. It is used to conduct standard and customized lightning and switching ?surge tests on small-capacity test objects (e.g. SCR thyristor valve) and inductors (Min. 1mH) etc. The ?generator and the control system are highly integrated in a 600mmx500mmx1200mm sized control cabinet. The impulse test system is manually or automatically controlled through a 5-inch touch screen mounted on control panel. The BNC on cabinet allows installation of measuring equipment such as digital oscilloscopes.?
Basic parameters
|
?Working power |
? ?AC 220V |
|
? ?Impulse voltage peak (adjustable) |
? ?20kV |
|
? Capacity (optional) |
? 1kJ |
|
? Mode of operation |
? ?MAN/AUT |
|
? (0~99.9μS)Delayed chopped |
? Optional |
|
? (0~3609)AC phase shift |
? Optional |
|
CDYX-10 portable impulse voltage generator |
