CDLD Impulse Current Generator For Test Residual Voltage And Motion Load Of Valve Discs

Product

D type impulse current generator

Type

CDLD

Structure

D type

Each unit consists of 2-4 horizontal large capacitors laid on the frame, a multi-tap inductor is vertically installed above the sphere gap; 2-6 units are laid around the sphere gap in D pattern; inductors can be adjusted according to wave form and test object resistive during tests

Functions

It is mainly used to test the residual voltage and motion load of valve disc, arrestor and SPDs.

Advantages

Good appearance

As shown in the photo

Module design

The charging unit, resistors, capacitor frame, sphere gap are separate functional modules for easy reconfiguration and repair.

Flexible combination

Flexible combination of different units and within the units enables generating wave forms of different energy.

Easy modulation

Flexible combination of inductors and capacitors for easy modulation

Compact design

Spark gap cylinder, test bay, measuring components are assembled on a base frame; compact design and low inductance

Stable and reliable triggering

Durable graphite spark gaps; gap distance is adjusted by a drive motor; impulse firing available with stable triggering

Mobility

Universal wheels on each module for easy displacement?

Stable performance

Long-time operation at a voltage lower than 80% of rated voltage

Performance

Current impulse

4/10μS

8/20μS

30/80μS

10/350μS

1000/2000μS

The impulse current generator and the charging unit are separate.

Charging unit with dual voltagerectification

Charging unit with automatic grounding and polarity reversal (external)

Encapsulated spark gaps with less noise

Capacitor with grounding device

Rogwoski circuits and dividers

Leading technologies and performance

Type

Rated current(kA)

Total energy(kJ)

Wave form(μS)

NO. of capacitors (n)

Main test objects

CDLD20/100

20

100

30/80,8/20

4

Valve disc, unit module

CDLD40/240

40

240

30/80,1000/2000

24

Valve disc, unit module

CDLD100/108

100

108

4/10,8/20,30/80

4

Valve disc, unit module

CDLD80/108

80

108

8/20,10/350

6

Valve disc, SPD

CDLD100/180

100

180

8/20,10/350

12

Valve disc,
