Stainless steel Expansion joint /flexible joint /Corrugated Compensator

stainless steel compensator/stainless steel expansion joint

Features:

· Extremely flexible

· Extremely durable

· Lasts the life of mechanical system

· Handles greater offsets without a compromise of hose integrity

· Good for applications where greater movement from building settlement and seismic

  activity is anticipated in a short OAL

· Vibration isolation

· Good for critical applications where maintenance and replacement would be costly

· Good for cold water, hot water and steam applications

· Available in a variety of end fittings

· Stainless steel end fittings standard

· No gaskets

Specification

Nominal diameter    1.5''-64''

Nominal pressure    0.6/1.0/1.6/2.5/4.0Bar

Compensation    18-400mm

Max. temperature    -40-450°C

Connection type    flange

Flange material    stainless steel/carbon steel

Flange standard    ANSI/DIN/JIS/BS/GOST/GB

Body material    SS304/316L

Usage:

Expansion Joint (Compensator) are commonly used to reduce vibration.To overcome minor piping misalignments and to reduce sound and vibration noise.

Executive standard:

GB/T12777-2008

Flange connector on both ends.
Size, diameter and length can be produced as per clients' requirements

1)  Structure: Bellows
2)  Main material: stainless steel 304
3) Compensates for exhaust converter misalignment
4) It is obtained ISO9001-2000 International Quality Certificated.
5) Expansion Joints are determined as " The Best Products of Chinese Technology" by China Technological Enterprise council and our company has the right of products Import & Export
