Papermaking Machinery Alloy Steel Corrugated Iron Roller , 270MM - 550MM OD

270MM - 550MM Out Diameter, 35CrMo, 48CrMoA Alloy steel Corrugated Iron Roller

Specifications:

Technical Parameters:

Corrugated rollers include in the upper corrugated roller and lower corrugating rollers, roller upper and lower surfaces both are tooth shape, two rollers matching meshing assembly. Lower corrugating rollers is active roller, motor driven run with low corrugated roller rotation? by the slow device. The upper corrugated roller is driven roller, relying on the roller gears of upper and lower rollers under the transmission mesh with each other.In order to make the corrugated base paper forming? bettwen upper and lower corrugated rollers, the upper corrugated roller must be pressured. So the upper corrugated roll not only around the rotation axis of itself, but also can go along the up and down corrugated roller line attachment direction.

Currently most manufacturers adopt composite processing, aftermid frequeney induction hardeningnitride or chrome plated, nitriding thickness of 0.5 ~ 0.6mm, plating chromic layer thickness of 0.10 ~ 0.15mm, chrome plated aftermid frequeney induction is main. The high quality corrugated rolles are made by soild forgings.

Applications:

Corrugated roller is commonly used to papermaking machinery and is the most important part of the corrugated paper edition production equipment and is an important key parts the single machine.The material are 42CrMo, 48CrMo, 45#, ect.
