Home > Products > Board to Board Connector > Board to Board LED Light Bar Connector 4.00 mm Pitch , Crimp 2 Pin Connector
Board to Board LED Light Bar Connector 4.00 mm Pitch , Crimp 2 Pin Connector
Negotiable
/ Kilogram
1 Kilogram(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
Pitch 0.5mm FFC / FPC Connector Single Row For Automotive Equipment
-
IDC Male Board In Connector PCB Board Connectors 2.5mm Pitch , Tin Contact Plating
-
Single Row Male DIP Plug PCB Board Connectors 2.54mm Pitch 10 Pin
-
Single Row PCB Board Connectors , IDC Male Connector Board - In Terminal 1.25mm Pitch
-
Female Wire to Board LVDS Connectors 0.5mm for Computer / MFP Related Equipments
-
Wafer IDC Male Connector Wire to Board , 0.6mm Crimp Style Connector 4 Pin - 12 Pin
Product Details
| Brand Name | SWB | Place of Origin | China | |
| Model Number | 4001WFX-02X |
Product Description
Certification:ISO9001/SGS/UL/RoHS/Reach
Board to Board Connectors 4.00 mm Pitch ?Crimp Style Connector of ?LED Light Bar
Specifications:
|
Product Name |
LED Light Bar?Connector |
|
Product Series |
Board to Board Connectors |
|
SWB Part Number |
4001WFX-02X |
|
Gender |
Female |
|
Pitch |
4.00mm |
|
No. of Rows |
1 |
|
No. of Contacts |
02 |
|
Orientation |
Straight |
|
Contact Material |
Phosphor Bronze |
|
Contact Plating |
Tin-Plated? |
|
Plastic Material |
LCP ?94V-0 |
|
Plastic Color |
Natural |
|
Current Rating |
3A AC/DC |
|
Voltage Rating |
300V AC/DC |
|
Operating Temp. Range |
-55℃~+105℃ |
|
Contact Resistance |
20mΩ Max |
|
Insulation Resistance |
1000MΩ Min |
|
Withstanding Voltage |
1700V AC/minute |
|
Wire Range |
AWG#28~32 |
? Competitive Advantages:
Precision mould manufacturing High-precision continuous stamping? Precision plastic molding and automatic equipment Making all-round quality management system Free samplesContact Us
