Brand Name	XINJE		Place of Origin	China
Model Number	XCC-24T-E

Product Description

Delivery Time:3-7 days
Certification:CE, ISO9001

5 Axis Pulse PLC High Speed Motion Control , Servo Motion Controller

Quick Detail:
?

24 I/O(input/output),

power supply AC220V,

XCC series motion control PLC (Programmable logic controller).

Powerful function: 5-axis high speed pulse output,?5 channels AB phase high speed counter, 2-axis interpolation function for CNC machine and other machines.

?
?
Description:
?

High performance motion control PLC

Support CAD motion control, support CAN bus

Fast floating instruction

Transistor output,?AC220V power supply

5?channels AB phase high speed count, 5-axis high speed pulse output (2-axis line, arc interpolation function)

?
?
Specifications:
?

Item	????????????????????? Specification
24-points
Scanning mode	Cyclic scanning, timing scanning
Programming mode	Instruction, ladder chart
Operation speed	0.5μs
Latched	Flash ROM and Li battery
Program capacity	256KB with secret download mode
I/O points	?14 digital inputs / 10 digital outputs
Internal coil(M)	8768 points
Process(S)	1024 points
Timer(T)	Points	640 points
Specification	100ms timer:0.1~3276.7s 10ms timer timer:0.01~327.67s 1ms timer:0.001~32.767s Interruption timer
Counter(C)	Points	640 points
specification	16-bit counter:K0~32,767 32-bit counter:K0~2,147,483,647
Data register(D)	8000 words
Flash ROM register(FD)	1024 words
Extension register(ED)	36864 words
High speed functions	High speed count, pulse output, external interruption
Timing scan period	0~99ms
Password protection	6-bit ASCII
Self-diagnosis	Power-on checking, monitoring timer, grammar checking

?
?
?Applications:?
?
24 I/O(input/output) motion control PLC (Programmable logic controller) can be used to packing machine, CNC machine, bending machine and so on.
????????
