Customized Gantry Welding Machine H Beam Welding Line 4000mm Rail Distance
- T/T L/C D/P D/A
- 7 days
You May Like
-
CNC Gas Cutting Machine / Plasma Cutting Equipment 12000*3200mm
-
High Efficiency T Beam / H Beam Welding Line Assembling Integrated Machine
-
Bolt Screw Adjustable Conventional Welding Rotator , AC Frequency Converter
-
Rotary Welding Table Top Welding Positioners Variable Frequency Control Speed
-
Automatic Steel Welding Table Homemade Welding Turntable , Height Adjustable
-
Blue , Red Fire Resistant File Cabinet / Acid Resistant Metal Lab Cabinets
Product Details
Brand Name | Friendship Machinery | Place of Origin | China | |
Model Number | MZG Series |
Product Description
Certification:CE, ISO
Gantry Welding Machine H Beam Welding Line Submerged Arc Welding Equipment
1. Technical?paramters
No. |
Item |
Specification |
1 |
Span?of?railway |
4000mm? |
2 |
Welding?method |
Vessel?welding |
3 |
Height?of?H?Web?beam |
200-1800mm |
4 |
Width?of?H?flange?beam |
200-800mm |
5 |
Thickness?of?Web?beam |
6-32mm |
6 |
Thickness?of?Flnage?beam |
6-40mm |
7 |
Length?of?h?beam |
4000-15000mm |
8 |
Return?speed |
3000mm/min |
9 |
Welding?speed |
150-1000mm/min |
10 |
Welding?sources |
SAW welding?machine |
11 |
Suitable?diameter?of?welding?wire |
3.2-5mm |
12 |
Drive?method |
bilateral |
2. Descriptions
● Rail distance: 4000 and 5000mm or customized
● Gantry type controlled by AC inverter displayed in digital, with functions of stable running and fast traveling speed
● Including 2 control types: middle and side control
● Mainly composed of gantry, carriage unit, mechanical tracing unit, flux recovery system, pneumatic system, electric system and SAW machine
● Middle gantry frame supports movable and 2 sides overhang installed welding arm work piece at locate both sides assistant rack for fillet welding in down hand
● Equipped with seam tracker, automatic flux feeding and recovery and wheels traveling unit
● Seam tracking and arc-guide mechanism used for return control and also can ensure welding gun centering without aberrancy
● Main machine and welder leakage control
H beam gantry welding machine adopts imported alternating frequency changer. It has stable function and fast kickback function. This arc guiding rack is triple axis mechanical tracing way, to ensure the welding gun aim at the correct position. Mainframe and welder are operated together. It is easily operated and high quality |
