Two Floors Row Residential Prefab Bungalow Steel Home Wind Proof For Family

Place of Origin	China
Model Number	Custom-made

Delivery Time:1 month
Certification:ISO, CE, BV

Two Floors Row Residential Light Steel Prefab Bungalow Modular Homes Custom Made

Description

Material: steel frame and sandwich panel Roof: 75mm PU sandwich panel Lifetime: more than 50 years Wind-proof: maximum 60 meters per second Fire resistance: all the materials used will be fire resistance Snow resistance: maximum 2.9KN/M2 as required Water and heat insulation: 100 mm in thickness can match more than 1m thickness of brick wall Seismic performance: more than 8 scales Insect prevention: Free from the damages by insects, such as white ants Acoustic insulation: 60db of exterior wall 40db of interior wall Ventilation: a combination of natural ventilation & air supply

Competitive Advantage

Safe structure with unlimited size request, can be built at anywhere. Light weight no matter the structure or panels are all lift easily lifted by man. Can come to be a upgrade house with simple decoration. Easy assembling job causing low cost on labor. Flat packed for transport which will make shipment economic and cheap. Fireproof, heat/cold-insulated, non-shrinking and enlarging work size with? little pollutions Life time is more than 50 years.

Specification

Light gauge steel channel

(II)	MAINTENANCE
EXTERNAL WALL	27mmPU EMBOSSED STEEL PANEL+HOUSE WRAP+12mmOSB BOARD+150mm INSULATION GLASS WOOL+12mm WATERPROOF GYPSUM BOARD
INTERNAL WALL	12mm WATERPROOF GYPSUM BOARD+150mm INSULATION GLASS WOOL
FALSE CEILING	0.5mm COLOR STEEL SHEET
9mm GYPSM BOARD
FLOOR SUPPORTING BOARD	1mm GALVANIZED MODELED FLOOR SUPPORTING BOARD
GALVANIZE
FLASHING EDGING	0.5mm SELF FOLDING COLOR STEEL SHEET
DOOR	1200*200mm STEEL DOOR
960*2050mm STEEL DOOR
800*210mm PVC MODELED DOOR
700*210mm PVC MODELED DOOR

Sample of the wall system

(III)	FITTINGS
HARDWARE	?
RAINWATER SYSTEM	75*50mmPVC RECTANGULAR TUBLE
PVC EAVES GUTTER(WITH ACCESSORIES)
ELECTRICITY	LIGHTS, SWITCHES, SOCKETS, DISTRIBUTION BOX
