move container steam boiler

The container boiler include:WNS series oil fired steam boiler,Electric box,Water solution system,Distributor,Water feed pump,Oil tank,Meter and Valve,etc.

These parts will be reveted in container,this type boiler can move freedom,its work only need turn-on the electrical source.It can be used in Derset,Oil filed,Montain,Wilderness,Road building site,etc.

The character of container boiler
1, convenient transport
2, compact structure
3, proper redistribution
4, the products are mature, we have much

5,Fuel can be Heavy oil, light oil,gas

experience in manufacturing this kinds of boilers We have sold dozens of this kind boilers to Thailand,Kazakhstan, Russia, Eastern Europe ect.
For example
Container boiler parameter
Boiler model  WNS1.5-0.7-Y(Q)  WNS2-1.25-Y(Q)
Nominal evaporation t/h  1500  2000
Nominal working pressure Mpa  0.7  1.25
Nominal steam temperature  169  194
Design efficiency  89  89
Light oil kg/h  108  150
Heavy oil kg/h  115  156
City gas Nm3/h  256  357
Natural gas Nm3/h  128  178
Main steam valve seat mm  DN65  DN80
Feed water tube diameter mm  DN25  DN25
Blowdown tube diameter mm  DN40  DN40
Safety valve tube diametemmr  2-DN40  2-DN40
Chimney diameter mm  350  350
Length mm  3300  3700
Width mm  1700  2000
Height mm  2100  2100

Install simply,Beautiful externality,Long haul practicality.

Welcome to visit our factory and product line.
