Strong Full HD DVB S2 Digital Satellite Receiver / Wireless Satellite Receiver for Home TV

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	OEM		Place of Origin	China
Model Number	RS-DM800 Se

Product Description

Delivery Time:25days after payment be confirmed
Certification:CE/ROHS

DM800hd se media player? DVB-S2 Digital Satellite Receiversim 2.10 Rev D11 Version? Sunray dm800 se

Specification:

400 MHz MIPS Processor	DM800 SE technical data:
- Linux Operating System	DBS-Tuner mit DVB-S2:
- OLED - Display	Frequency Range 950 .... 2150 MHz
- MPEG-2 / H.264 Hardware decoding	Demodulation DVB-S (QPSK); DVB-S2 (8PSK,QPSK)
- Tuner: DVB-S, optional: DVB-C, DVB-T	Symbol rate DVB-S: 2 ... 45 Mbaud/s, SCPC/ MCPC
- Tuner Module, Plug&Play	DVB-S2: 10-31 Mbaud/s (8PSK) , 10-30 Mbaud/s (QPSK)
- 1 x Smartcard-Reader	Video decoder:
- V.24/RS232 Interface	Video Compression MPEG-2 and MPEG-1 compatible, H.246
- 10/100Mbit Ethernet Interface	Video Formats 4:3 / 16:9
- 1 x Scart (RGB, FBAS or S-Video)	Letterbox for 4:3 TV-Device
- HDMI	Audio decoder:
- 2 x USB 2.0	Audiokompression MPEG-1 & MPEG-2 Layer I and II, MP3
- analog modem	Audio Mode Dual (main/sub), Stereo
- S/PDIF Interface for digital bit stream out (AC-3)	Frequency: 32 kHz, 44.1 kHz, 48 kHz, 16 kHz, 22.05 kHz, 24 kHz
- 64 MByte Flash, 256 MByte RAM	Output analog:
- SATA	Output Level L/R 0,5 Vss on 600 Ohm
- for use either as internal SATA HDD 2,5\'\'	THD > 60 dB (1 kHz)
- or to use for extern eSATA	Crosstalk < -65 dB
- unlimited channel lists for TV/Radio	Output digital:
- channel-change time < 1 second	Output Level 0,5 Vss on 75 Ohm
- automatic service scan	Sampled Data Filtering 32 kHz, 44.1 kHz, 48 kHz
- directly bouquet-lists	S/PDIF-Output optical, Toslink
- EPG (electronic program guide)	Ausgang Video:
- multiple LNB-Switching control (supports DiSEqC)	Ausgangspegel FBAS 1 Vss 0.3 dB an 75 Ohm
- OSD in many languages and skin-support	Video parameter:
- Videotext Decoder	Input Level FBAS 1 Vss 0.3 dB on 75 Ohm
- extern 12V power supply	Teletext filter in conformity with ETS 300 472 Standard
	TV-Scart:
	Output: FBAS, RGB, S-Video
Serielle Interface RS 232:	Ethernet:
Typ RS232 bidirectional	10/100 MBit compatible interface
Bitrate 115,2 kBit/s max.	Function: Update of Firmware
Plug Connector SUB-D-9	Analoge modem:
Function: Update of Firmware	analoge modem for Internet connection
LNB power and polarisation per tuner:	SATA Interface:
LNB Current 500mA max.; short-circuit-protected	- for use either as internal HDD 2,5\'\' or eSATAor internal 2,5\" HDD
LNB Voltage vertical < 14V no load, > 11,5V at 400mA	USB
LNB Voltage horizontal < 20V no load, > 17,3V at 400mA	2 x USB 2.0 Host
Count of active satellite position:	Power consumption:
DiSEqC 1.0/1.2 SAT POSITION / SAT OPTION	< 15W at 12V
DiSEqC - Rotor Control	Physical specification:
External PSU	Ambient Temperature +15°C...+35°C
Input:	Humidity < 80%
110-240V AC / 50-60Hz / 0,6A	Size (W x D x H): 195 mm x 140 mm x 40 mm
Output:
12V = / 3,0A
