Original OPENBOX X5 HD DVB-S2 Digital Satellite Receiver IPTV Support Internet Ethernet

Original OPENBOX X5 HD DVB-S2 Digital Satellite Receiver IPTV Support Internet Ethernet

Description:

High-performance 667MHz 32-bit MIPS 24KEc Processor

Supports MPEG-2 (ISO/IEC 13818-2) MP HL and MP ML for HD and SD decoding

Supports MPEG-4 (ISO/IEC 14496-2) extended ASP

Supports H.264 (MPEG-4 AVC, ISO/IEC 14496-10) MP/HP L4.1 for SD and HD decoding

Supports RealVideo(RealPlayer v8,9,10), DivX 3.11/4.12/5/6/HD, and Xvid,

Supports WMA and WMA-pro, Dolby MS10 option, RealAudio

Supports various bit rates for MPEG-1 Layer I/II, AC-3 and E-AC-3

Supports HDMI 1.3 transmitter with HDCP, 1080i/p, 720p,576i/p and 480i/p outputs

Supports dual USB2.0 EHCI host controllers with PHY embedded

Supports 1-bit or 2-bit SPI flash memory

IR receiver/transmitter

VFD driver interface

Supports dual Smart card controller interfaces

Supports PCMCIA controller interface for CI/CI+ applications

MHEG5 HD middleware UK DTG Certified

10/100 MAC with PHY

Automatic and manual channel scan options;

Automatic service scan

Channel-change time < 1 second

OSD in many languages and skin-support

Multilingual support on screen menu (OSD): English, French, Deutsch, Italian, Spanish,

Swedish, Danish, Greece, Portuguese, Finland, Holland, Turkish, Czech, selectable

LED Display

Analog audio output: stereo(L+R);

YCbCr available;

1 x Scart (RGB, FBAS or S-Video)

Screen format: auto, 4:3, and 16:9;

Upgrade software through USB2.0 port;

Powerful program management function, parent lock;

Directly bouquet-lists

Sunplus 1512A? Solution?,???AV? or? SCART optonal

TECHNICAL SPECIFICATIONS

Front Panel

Display:4-digital 7 segment LED display with Green color

Smart Card Slot: 1

USB 2.0: x 1

Key: Standby, Menu, Exit, CH-, CH+, VOL-, VOL+

Rear Panel

Power Swithch:1

Sat-IF Input/Output: 2 x F-types socket

Connection TV:1 x Scart socket

Video Output(Analogue): 3 x Cinch socket(YPbPr)/1 x Cinch socket

Video/Audio Output(Digital): 1 x HD

Audio Output(Analogue): 2 x Cinch socket

USB 2.0: x 1

Ethernet :1

RS-232 :1

Power

Mains Voltage 100-240V/50-60Hz

Power Consumption(Max.) 20W

RF

RF Range 90~2150MHz

Modulation, FEC DVB-S/DVB-S2 standard

Video

Video Resolution : 1080p,1080i, 720p,576p,

Video decoding : MPEG-2, MPEG-4 compatible

Input data rate : 2-45 MSymb/s

S/N >53dB

Decoding

Decoding : AC 3, MPEG-4 (AAC-HE), MPEG-1, Layer 1, 2 and 3

Sampling Rate : 32/4.1/48kHz

S/N ; >65dB

LNB

LNB Supply(Horiz./Vert.) 13/18V

Control Signal 22kHz ; ToneBurst ; DiSEqCTM1.0/1.1/1.2

Carton size: 495*275*2500mm

10?pcs/carton, 12KG/carton

20 /40 /40 HQ:8000/15000/18000pcs

Packing Details:

?1x?X5 HD Box

?1x Remote control

?1x Power Supply Cable

?1x HDMI Cable

?1x User Manual
