Aluminum / Iron P16 1R1G1B Full Color Outdoor SMD LED Display For Rental Backdrop Screen

SBO-P16SMD (Pitch 16mm outdoor full color)

Pixel structure

1R1G1B, 3in1

Pixel pitch

16mm

Pixel density

3, 906 dots/㎡

Luminance

5, 500cd/㎡

Module dimension

256mm(W) * 128mm(H)

Module resolution

16 pixel(W) * 8 pixel mm(H)

Cabinet dimension

1024 * 768mm

Cabinet resolution

64 * 48

Cabinet area

0.786 sq. meter

Optimal visual distance

>15m

Visual angel

140 / 140 degree (H/V)

Max power consumption

≤1000w / ㎡

Average power consumption

≤600w / ㎡

Brightness adjustment

Adjust according to the environment

brightness software (0%-100%adjustable)

Gray scale

point by point 4096 gray grade levels of

each color, 16 bits γ correction available

Drive mode

Static, constant current

Frame frequency

≥60HZ

Refresh frequency

≥1000HZ

Input voltage

AC 90~260 volts

Operation temperature

﹣40℃~ +65℃

Operation humidity

10％～90％

Input signal

S-video, RF, RGB, Yuv, YC, composite…

Control system

DVI card + master control card + receiver card

MTBF

>5000 hrs

Life span (50% brightness)

100, 000 hrs

Malfunction dot rate

1/10000

Ingress protection rate (Front/ rear)

IP65 / IP54

Cabinet material
