1mm Material Thickness 16 Stations Roof Bemo Panel Roof Roll Forming Machine With CE

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	TECHWELL		Place of Origin	China
Model Number	TW-STM400

Product Description

Delivery Time:55-65 working days
Certification:CE

1mm Material Thickness 16 Stations Bemo Panel Roof Roll Forming Machine With CE

??Maintenance of?Bemo?Panel?Roll Forming Machine ?

Daily maintenance plays an very importance role in extending the operation time and?of Bemo?panel roll forming machine and the good quality finished?bemo roof. The following points should be part of the machine\'s daily production and usage routine.

Regularly lubricated the outside parts of the bemo roofing sheet?roll forming machine, such as the driving chain... Regularly brush the surface of roller, particularly when working outside. If you do not use the bemo roof panel forming machine in a long time, you should apply luricating oil on the roller surface, make sure you clean it for next time running machine. If the bemo panel roll forming machine is not operated in a long period, should cover it with plastic film, to avoid getting rain or dust on the machine, or avoid the machine becoming damp, especially the PLC electric control board. Make sure the cutting system is lubricated when necessary. Check the Hydraulic station often and the oil quantity of the deceleration machines, add more oil if the oil level is low. Check the electric appliances box and every leads conjuction circumstance of the?bemo roof?sheet roll?forming machine.

? Main Specifications of Roof Bemo Panel Roll Forming Machine ?

?Item	?Bemo Panel Roll Forming Machine
?Coil Material ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?	?Thickness	?0.3-0.8mm ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?
?Coil width	?Custom-made
?Yield Strength???????????	?250-350 Mpa
?Material	?GI.?Aluminium,PPGI, Color Steel,
?Decoiler / Uncoiler	?Decoiler Type	?Manual or Hydraulic or Auto Type
?Coil Width	?Max. 1250mm
?I.D	?508-610mm
?O.D	?Max. 1500mm
?Bemo Panel Roll?Forming?Machine	?Forming Stations	?13 Stations ( Depend on Profiles )?
?Roller material?	?45# steel, surface coated with 0.05mm hard? chrome?? ? ? ? ? ? ? ? ? ? ??
?Diameter of shaft?	?76mm
?Shaft material	?High grade 45# steel
?Drive type	?Chain transmission
?Forming speed	?0-15m/min
?Main power	?5.5KW
?Cutting?System????????????????????????????????????????????????	?Cutting type	?Hydraulic cutting
?Cutting Die Material	?Cr12Mov steel, HRC58-62
?Cutting power	?3KW
?CuttingTolerance	?10m1.5mm
?Encoder	?OMRON Brand
?Electrical Control Box	?PLC??????????????????????????????????	?PANASONIC Brand
?Inverter	?YASKAWA Brand
?Touch screen	?PANASONICE
?Operation type	?Touch screen & Button
?Hydraulic Station	?Hydraulic station	?Famous Chinese brand
?Support Tables	?Table type	?Simple nonpower type
?Function	?To support the finished panels

? Main Components of Bemo Panel Roll Forming Machine??

?Decoiler / Uncoiler	?1 Unit ? ? ??
?Feeding Guide	?1 Unit
?Main?Bemo Panel?Roll Forming Machine	?1 Unit
?Hydraulic Cutting Device????????????????????????????????????????	?1 Unit?????????????? ??????????????
?Hydraulic Station
