Continuous dyeing Wool Scouring Machine Stainless steel output sheet

Brand Name	KD		Place of Origin	China
Model Number	B061-A

Delivery Time:20 days after confirmed
Certification:CE Mark

Continuous dyeing Wool Scouring Machine Stainless steel output sheet

B061-A Wool Drying Machine / Continous dyring Stainless steel output sheet

B061-A Wool Drying Machine

Application:

Textile Drying Machine is suitable for wool, wool-washing process and other bulk fiber drying.

The main specifications:

Working way: continuous drying type

Output plate and outlet height: 1196.5mm

Width of output sheet: 1768mm

Output sheet size: 20.5 m2

Output speed: 0.137~0.92m/minutes

Cooling area: 138 m2

Steam working pressure: 4Kg/cm2

Heating method: Aluminum strips around the tube

Chamber temperature: first section: 65℃～70℃

??????????????????????????????????? Second section: 102℃～104℃

??????????????????????????????????? Third section: 104℃～108℃

(The above refers to the carbonization temperature, if used for simple drying temperature needed to lower a bit. )

After drying moisture: 10～13％

Fan speed: 1000 Rev/min

Upper fan air flow: ≈ 14900 m3/h

Lower fan air flow: ≈ 13700 m3/h

Transmission mode:

Curtain: individual motor variable frequency stepless speed v-belt, turbine gearbox and chain drive. Shape size: L12775mm ?W3450mm ?H2635mm productivity: ?110 kg/h~350kg/h Motor:?? 2.2KW ?380V ?960 RPM ??????????6 sets ?????????????2.2KW 380V 960 RPM????????? ?????1 set Reducer: 4M? speed radio: 1:5? power: 1.5KW?? 1 set V-belt: ?A type? 1905(A75″) ???????????????2 pcs

Textile Drying Machine structure:

Textile Drying Machine is delivered from the chassis fan, blinds, heaters and other combinations formed. Racks are for the channel, angle iron and other components, main room with side fit two parts, steel isolation, main room installation of supply air curtain Panel heater and insulation plate, side fit fan is installed, transmission, gearbox. In order to prevent heat loss, surrounded by walls with insulation, main room equipped with a door that can be opened to facilitate repairs, topped with 2 open the exhaust air, moist air out of the body, but interface has an active regulator in order to regulate discharges of moist air, and another rectangular hole to adjust the air flow. Fan mounted to the right, 4 fans are upper, 2 are lower, fan centrifugal type impeller made of steel plate, the fans are managed by a separate motor. In main indoor II side with angle Guide, above has continuous of conveying Board, each block conveying Board of surface has many neatly of small hole, II end with rolled child Board-like chain makes each block conveying Board coupling growth and wide of conveying curtain, it is by chain drive, another end of sprocket axis frame can regulation, makes conveying curtain has appropriate of tension, in side indoor with motor through deceleration box makes whole conveying curtain in angle guide Shang slowly mobile. Heating system via the steam pipe into the steam heater, heater and 3 groups, arranged for 2 groups of upper, 1 lower part are choke trap. Textile Drying Machine is equipped with 24 chock plates, its main role is to regulate under the circumstances inside the oven air blows hot air evenly to all layers. Transportation Board change of speed is stepless transmission speed ratio changes, based on specific requirements could rotate speed control handwheel stepless transmission speed by the Transportation Board.
