240W All in One Background Amplifier PA System with 20 zones and 2 mics port

240W All in One Background Amplifier PA System with 20 zones and 2 mics port

Quick Detail:

? Background Music System

? Emergency Public Address System

? Alarm System

? Paging System

? 5-20 zones, 240W-1920W

Applications:

All in One BGM & PA System is an economical solution for small to medium installations that offers outstanding performance and a wide range of features. This high performance, yet affordable unit is

very easy to install and operate.?

used at : office buildings, workshops, small shopping arcades, schools, factories, sports clubs,

factories etc.

Features:

Audio Source:

? Built-in CD/DVD

? USB / MP3

? FM/AM tuner

? 1 AUX Input

? 1 EMC Input

? 2 MIC Input?

? Audio source can be selected via the front panel.

Output:

? 100V output for speaker?

? 5 output zones can be selected on or off? via the front panel switches

? Each zone volume can be adjusted independently

? Output level is monitored via the LED VU meter

? PC connector for pre-program the music

? AV output for video show

Alarm System:

? There are Alarm Short Circuit Trigger Connector, could connect with the Alarm System of Smart home.??

? Offering outstanding performance and featuring microphone, auxiliary and emergency inputs.

Paging & Broadcast

? 4 paging microphone?can be connected within 1Km distance for 4 places.

? Mic Input: Two 6.35mm Jack make your broadcast and paging easily.

? RJ-45 inputs are provided on the rear panel.

? When you paging to one zone, won’t interrupt other’s zones background music

Built-in Weekly Timer

? Has 20 weekly schedules that can be individually programmed?

? Each day of the week has a separate event set, which means that 20 separate schedules can be programmed for any one day.

? 99 events can be set up,each of which can be programmed to an accuracy of one second.

? One Edit key at the front panel can timing all the pre-program

? Also can be program via PC

Extend:

? Can be expanded to up to 20 zones and also the volume of each zone can be controlled independently

Competitive Advantage:

? 5 output zones can be selected via the front panel switches

? 4 music source (CD/DVD, MP3, FM/AM, AUX) and MIC can be selected via the front panel.

? Editor in front panel can Pre-program the music at any time and any zone??

? AV output

? can be extended up to 20 zones.

? 4 main functions of (BGM, PA Alarm and Paging) make it to be the top All In One PA Systems

Technical Specification
