Speed Control Three Phase / Single Phase Frequency Inverter 2.2KW 50HZ

Brand Name	HNC Automation		Place of Origin	China
Model Number	HV850

Delivery Time:3-14 days on payment
Certification:CE, 3C

Automation Machines Three Phase / Single Phase Frequency Inverter 2.2KW
?

AC 220V Single phase Frequency Inverter Power range: 0.4KW, 0.75KW, 1.5KW, 2.2KW Mini size frequency inverter to save the installation space Built-in serial communication interface, using standard Mod-bus communication protocol Built-in the function of the textile-specific swing band? Best performance-cost ratio to help customer save the cost

?
Description:

?
Selection Guide

Model	Rated output power(KW)	Rated Output Current(A)	Motor Power(KW)
HV850-0R4G1	0.4	3.0	0.4
HV850-0R8G1	0.75	5.0	0.75
HV850-1R5G1	1.5	8.0	1.5
HV850-2R2G1	2.2	10.0	2.2

Features of HV850 Single Phase frequency Inverter

HV850 series inverter uses a simplified vector control technology to achieve extensive application of functional blocks. It meets the requirements for high torque and improves the dynamic response and motor control features by using automatic fully frequency band and output torque compensation. With proportional, integral and differential (PID) control function of the closed-loop control, it can be used for process control, such as constant pressure water supply. Built-in the function of the textile-specific swing band. Fast current limit (FCL) function, to avoid undue running trip. Built-in DC injection braking. Acceleration / deceleration ramp features have a programmable smoothing function. Overvoltage stall prevention, the inverter automatically limits the increase of DC bus voltage during the run time. Fault and fault query monitoring features. Built-in serial communication interface, using standard mod-bus communication protocol.

?
Applications:
HV850 series is a general single phase frequency inverter. It could match most of applications with single phase power supply. For example, constant pressure water supply, conveyor belt, textile-specific swing band, automation machines.
?
?

Specifications:

Items	Criterion

Performance

Frequency range

0～600Hz

Precision of output frequency

0.01Hz

Resolution of setting frequency

Digital setting:0.01Hz.

Analog setting:AD switch precision for one in thousand, linearity for +-5%.

Speed range

1:100

Overload capability

HV850S series:150％rated current 60s;180％rated current 2s.

HV850T series(G model):150％rated current 60s；180％rated current 2s.

HV850T series(P model):120％rated current 60s；150％rated current 2s.

remark:may obtain the informations of model and power in “d1 function groups”.

Control Mode

Open-loop simple vector control

Torque boost

Manual torque can be adjust；Auto-Torque upgrades the whole frequency band.

Start up Torque

when0.5Hz, rated torque for 150％.

Function

descriptions

Acc and Dec time

0.1～3200.0s

Jog function
