Infant radiant warmer

Brand Name	Mediconex		Place of Origin	China
Model Number	MDN-100 ( Top grade ）

Brief introduction:
☆Microprocessor based servo controlled
　 temperature system.
☆The microprocessor-controlled unit allows for
　 three settings: pre-warm, manual or automatic.
☆A(yù)larm functions for safety includes:
　　 Power failure;
　　 Temperature deviation;
　　 Temperature sensor failure;
　　 over temperature;
☆A(yù)PGAR timer to record therapy time
☆Convenient X-ray cassette under infant bed
☆Heater head can be adjusted  + 90o horizontally
☆Tilt angle of infant bed is adjustable
☆Observe light angle is adjustable
☆Transparent protector folded
☆A(yù)dopts anti-explosion micro crystal quartz infrared
　 radiation tube for its radiation source,the heating
　 is quick and life-span is long
☆A(yù)larms are audible and visual
☆A(yù) second thermal cut-out function for more safety
☆Skin temperature sensor failure protect function
　 avoid over temperature
☆Temperature deviation can be amended in front
　 panel directly
☆Low pressure aspirator, oxygen supply system
　 and LED phototherapy unit

 Technical data:
　1.Power supply : 110/220V   60/50Hz
　2.  Power input: ≤1200VA
　3. Operating condition:
　　　 An ambient Temperature:18℃-30℃
　　 　An ambient Relative Humidity: 30%--75%RH
　　　 Atmospheric Pressure: 700～1060 hPa
　　　 An ambient Air Velocity ＜0.3m/s
　4. Temperature control: 32℃～38℃
　5.Temperature control accuracy: ≤0.5℃
　6.Mattress temperature uniformity : ＜2℃
　7.Skin temperature sensor accuracy: + 0.3℃
　8.Warm-up time: ≤30min
　9. Infant Bed tilt angle:+ 10°
　10.APGAR timer range: ≤24h
　11.Heater head horizontal: ±90°
　12.Mattress size: 67cm× 54cm
　13.Distance from heater to mattress:80cm
　14.Height adjustable range:0-20cm
　15.LED phototherapy light: 2pcs × 8W

Standard configuration:
　Main body (including the radiant source, control system, infant bed, bracket), X-ray cassette , Observe light , I.V.pole, skin temperature sensor, tray, mattress, transparent protector, castors.
LED phototherapy unit ,low pressure aspirator; oxygen supply system.

Optional parts:
　 Drawer,;
　 RS-232(485) connector;

Transport and storage:
　Environment Temperature:-40℃~ +55℃
　Environment Relative Humidity: ≤95%
　Atmospheric Pressure: 500～1060hPa

Package:
　Each unit is packed one case
　　Size:135cm×85cm × 98cm
　　Gross weight: ≤170kg
