Press Beam Moving Type Steel Plate Milling Machine Four Driving Head
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
40 Ton Fit-up Electric Welding Turning Rolls For Wind Tower Production
-
200 Tons Self-Aligned Pipe Turning Rolls For 7 Meters Diameter Tank
-
Motorized Lead Screw Welding Tank Turning Rolls Vessel Rotator HGZ - 100 T
-
300 Tons Motorized Lead Screw Adjustable Tank Turning Rolls Low Noise
-
250 Ton Bolt AdjustableTurning Rolls Vessel Rotator For Tank Oil And Gas
-
Small Screw adjust Pressure Vessel Welding Turning Rolls HGK - 100 T
Product Details
| Brand Name | Pyramid | Place of Origin | China | |
| Model Number | XBJ-series |
Product Description
Certification:CE,ISO,TUV
?Press Beam Moving Type Steel Plate Milling Machine Four Driving Head YXB-18
Quick Detail:
Name: Press Beam Moving Type Milling Machine Brand:Pyramid 3.Type:YXB-18Description:
This machine is large-scale milling equipment which can mill both sides of workpiece at the same time. There is four driving head installed on machine body which can improve the working efficiency greatly. The presser beam is movable type, it is easy for user to feed material before processing and lay off material after processing.
Applications:?
?It can mill both sides of workpiece at the same time.
Specification
|
Model |
YXB-18 |
|
Plate thickness |
10-160mm |
|
plate width |
≤18000mm |
|
milling moving speed |
130-1200mm/min |
|
milling return speed |
1500mm/min |
|
hydraulic working pressure |
0.5-3.5Mpa |
|
presser beam moving distance |
1000mm |
|
feeding motor power |
1.5KW(frequency control) |
|
milling motor power |
7.5KW(gear control) |
|
presser beam motor power |
2*1.5KW |
|
hydraulic presser foot number |
19 pieces |
Competitive Advantage:
Compared with the traditional edge milling machine , there is more flexibility and high efficience.
