Sell DQm serise Pump

Place of Origin	China

Model No.:
Product Origin:China
Brand Name:
Price Terms:
Payment Terms:
Certification:
Description:Model No. PowerInlet/outletMax.FlowMax.HeadMax.SuctG.W. Packing Quatity.20" HP L/MIN M M KG MM SET DQm60 0.5 1"X1" 40 40 8 6 283*152*174 3300 DQm70 0.8 1"X1" 50 65 8 9.5 325*180*210 2360 DQm80 1 1"X1" 60 70 8 11.2 345*180*210 2220 Pump installation and applications: These pumps are suitable for handling clean water not containing abrasive particles and fluids which are not chemically aggressive to the pump components. Reliable, economical and simple to use, these products are suitable for domestic applications, automatic distribution of water from surge tanks, watering gardens and for boosting insufficient mains water pressure. They pumps should be installed in a covered area, protected against the weather. Structural characteristics: 1) Cast iron pump body 2) Stainless steel mechanical seal (graphite to ceramic) 3) Brass impeller with radial peripheral blades 4) 45# steel shaft Operating conditions: Liquid temperature: up to 35oC Ambient temperature: up to 40oC Motor: 220V / 50Hz or 220V, 110 - 220V / 60Hz models are available on request
